List of products by manufacturer SIBA

Fuse 14x51 gR 690V (IEC)/700V (UL) 12A

Fuse 14x51 gR 690V (IEC)/700V (UL) 12A

Reference 5012406.12.0 - Manufacturer SIBA
Class gR
Rated current In (A) 12
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 3,1
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 8,1
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 75
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €9.55/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 16A

Fuse 14x51 gR 690V (IEC)/700V (UL) 16A

Reference 5012406.16.0 - Manufacturer SIBA
Class gR
Rated current In (A) 16
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 4,7
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 11
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 115
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €14.70/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC) 2A

Fuse 14x51 gR 690V (IEC) 2A

Reference 5012406.2.0 - Manufacturer SIBA
Class gR
Rated current In (A) 2
Rated Voltage Un AC (V) 690
Applicable standards IEC
Power loss (W) 1
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 2,6
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 7,7
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €12.20/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 40A

Fuse 14x51 gR 690V (IEC)/700V (UL) 40A

Reference 5012406.40.0 - Manufacturer SIBA
Class gR
Rated current In (A) 40
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 10
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 140
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 1050
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €17.86/pc
Quantity
lock Datasheet
Fuse 14x51 gRL/gS 690VAC/400VDC 10A

Fuse 14x51 gRL/gS 690VAC/400VDC 10A

Reference 5012434.10.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 10
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 1,9
Rated Voltage Un DC (V) 400
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 70
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 22
Price List €9.73/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 8A

Fuse 14x51 gR 690V (IEC)/700V (UL) 8A

Reference 5012406.8.0 - Manufacturer SIBA
Class gR
Rated current In (A) 8
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 1,7
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 5,1
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 28
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €14.08/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 6A

Fuse 14x51 gR 690V (IEC)/700V (UL) 6A

Reference 5012406.6.0 - Manufacturer SIBA
Class gR
Rated current In (A) 6
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 1,3
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 2,9
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 18
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €14.01/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 50A

Fuse 14x51 gR 690V (IEC)/700V (UL) 50A

Reference 5012406.50.0 - Manufacturer SIBA
Class gR
Rated current In (A) 50
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 12
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 250
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 1900
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €18.69/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 32A

Fuse 14x51 gR 690V (IEC)/700V (UL) 32A

Reference 5012406.32.0 - Manufacturer SIBA
Class gR
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 9.5
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 63
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 620
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €13.75/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC)/700V (UL) 25A

Fuse 14x51 gR 690V (IEC)/700V (UL) 25A

Reference 5012406.25.0 - Manufacturer SIBA
Class gR
Rated current In (A) 25
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 7,6
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 32
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 340
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 20
Price List €15.04/pc
Quantity
lock Datasheet
Fuse 14x51 gR 690V (IEC) 3A

Fuse 14x51 gR 690V (IEC) 3A

Reference 5012406.3.0 - Manufacturer SIBA
Class gR
Rated current In (A) 3
Rated Voltage Un AC (V) 690
Applicable standards IEC
Power loss (W) 1,5
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 15
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse 14x51 gRL/gS 690VAC/400VDC 12A

Fuse 14x51 gRL/gS 690VAC/400VDC 12A

Reference 5012434.12.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 12
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 2,3
Rated Voltage Un DC (V) 400
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 105
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 22
Price List €9.56/pc
Quantity
lock Datasheet
