Fuse 10x38 600VDC gPV 25A

Fuse 10x38 600VDC gPV 25A

Reference 491940.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 25
Applicable standards IEC
Power loss (W) 2,74
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 280
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 460
Weight (gr) 10
Price List €21.41/pc
Quantity
Fuse 10x38 600VDC gPV 20A

Fuse 10x38 600VDC gPV 20A

Reference 491935.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 20
Applicable standards IEC
Power loss (W) 2,9
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 85
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 212
Weight (gr) 10
Price List €21.41/pc
Quantity
Fuse 10x38 600VDC gPV 16A

Fuse 10x38 600VDC gPV 16A

Reference 491930.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 16
Applicable standards IEC
Power loss (W) 2,7
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 30
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 82,8
Weight (gr) 10
Price List €21.41/pc
Quantity
Fuse 10x38 600VDC gPV 15A

Fuse 10x38 600VDC gPV 15A

Reference 491929.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 15
Applicable standards IEC
Power loss (W) 2,44
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 25
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 82,8
Weight (gr) 10
Price List €20.86/pc
Quantity
Fuse 10x38 600VDC gPV 12A

Fuse 10x38 600VDC gPV 12A

Reference 491925.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 12
Applicable standards IEC
Power loss (W) 2,6
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 25
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 62,8
Weight (gr) 10
Price List €21.41/pc
Quantity
Fuse 10x38 600VDC gPV 10A

Fuse 10x38 600VDC gPV 10A

Reference 491920.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 10
Applicable standards IEC
Power loss (W) 2,58
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 11
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 27,9
Weight (gr) 10
Price List €21.41/pc
Quantity
Fuse 10x38 600VDC gPV 8A

Fuse 10x38 600VDC gPV 8A

Reference 491915.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 8
Applicable standards IEC
Power loss (W) 2,55
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 25
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 55
Weight (gr) 10
Price List €21.41/pc
Quantity
Fuse 10x38 600VDC gPV 6A

Fuse 10x38 600VDC gPV 6A

Reference 491910.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 6
Applicable standards IEC
Power loss (W) 2,4
Rated Voltage Un DC (V) 600
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 8,5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 600
Total clearing I²t @Un AC (A²s) 18,8
Weight (gr) 10
Price List €21.41/pc
Quantity
C200 - Fuse 690VAC aR 900A size 2 61x52,4mm M10 flush end terminals

C200 - Fuse 690VAC aR 900A size 2 61x52,4mm M10 flush end terminals

Reference 492.016.10.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 900
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 105
Series name C200
Fixing dimensions M10
Melting I²t value (A²s) 170000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 1173000
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
Fuse 690V aR 10x38 without striker 4A

Fuse 690V aR 10x38 without striker 4A

Reference 491113.0.0 - Manufacturer DF
Class aR
Rated current In (A) 4
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 1,6
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 4,9
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 10
Weight (gr) 8
Price List €6.49/pc
Quantity
Fuse 14x51 gPV 1000VDC 25A

Fuse 14x51 gPV 1000VDC 25A

Reference 491650.0.0 - Manufacturer DF
Class gPV
Rated current In (A) 25
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 275
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 20
Price List €25.81/pc
Quantity
Fuse 690V aR 14x51 with striker 8A

Fuse 690V aR 14x51 with striker 8A

Reference 491730.0.0 - Manufacturer DF
Class aR
Rated current In (A) 8
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 1,01
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 4,1
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 23
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 18
Price List €11.79/pc
Quantity
