BPF1 - Fuse 1500VDC aBat d:50mm M8 630A

BPF1 - Fuse 1500VDC aBat d:50mm M8 630A

Reference 219.625.98.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 630
Applicable standards IEC
Power loss (W) 105
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name BPF1
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 50x168
Melting I²t value (A²s) 242250
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 847900
Product available on request Ask for more information
G103 - Fuse 500V 10x38 gG 32A

G103 - Fuse 500V 10x38 gG 32A

Reference 236.479.64.0.0 - Manufacturer FAULTRAP
Class gG
Rated current In (A) 32
Rated Voltage Un AC (V) 500
Applicable standards IEC
Power loss (W) 2,7
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 93,5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 578
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
V103 - Fuse 10x38 1000VDC gPV 4A

V103 - Fuse 10x38 1000VDC gPV 4A

Reference 238.967.87.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 4
Applicable standards IEC, UL
Power loss (W) 1,69
Rated Voltage Un DC (V) 1000
Series name V103
Rated breaking capacity I1 DC (kA) 20000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 10,1
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 24
Price List €8.73/pc
Quantity
lock Datasheet
Fuse SQB3 screw M12 aR 1000V no ind 1100A

Fuse SQB3 screw M12 aR 1000V no ind 1100A

Reference 2078031.1100.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1100
Rated Voltage Un AC (V) 1000
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 174
Fixing dimensions M12
Melting I²t value (A²s) 443000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2400000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 800V no ind 1250A

Fuse SQB3 screw M12 aR 800V no ind 1250A

Reference 2078031.1250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1250
Rated Voltage Un AC (V) 800
Dimension SBQ3
Applicable standards UL
Power loss (W) 198
Fixing dimensions M12
Melting I²t value (A²s) 652000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2350000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 800V no ind 1400A

Fuse SQB3 screw M12 aR 800V no ind 1400A

Reference 2078031.1400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1400
Rated Voltage Un AC (V) 800
Dimension SBQ3
Applicable standards UL
Power loss (W) 210
Fixing dimensions M12
Melting I²t value (A²s) 852000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2800000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 315A

Fuse SQB3 screw M12 aR 1250V no ind 315A

Reference 2078031.315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 83
Fixing dimensions M12
Melting I²t value (A²s) 11000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 60000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 350A

Fuse SQB3 screw M12 aR 1250V no ind 350A

Reference 2078031.350.0 - Manufacturer SIBA
Class aR
Rated current In (A) 350
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 85
Fixing dimensions M12
Melting I²t value (A²s) 15000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 900000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 400A

Fuse SQB3 screw M12 aR 1250V no ind 400A

Reference 2078031.400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 400
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 92
Fixing dimensions M12
Melting I²t value (A²s) 22000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 130000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 450A

Fuse SQB3 screw M12 aR 1250V no ind 450A

Reference 2078031.450.0 - Manufacturer SIBA
Class aR
Rated current In (A) 450
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 99
Fixing dimensions M12
Melting I²t value (A²s) 33000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 190000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 500A

Fuse SQB3 screw M12 aR 1250V no ind 500A

Reference 2078031.500.0 - Manufacturer SIBA
Class aR
Rated current In (A) 500
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 110
Fixing dimensions M12
Melting I²t value (A²s) 42000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 230000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 550A

Fuse SQB3 screw M12 aR 1250V no ind 550A

Reference 2078031.550.0 - Manufacturer SIBA
Class aR
Rated current In (A) 550
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 115
Fixing dimensions M12
Melting I²t value (A²s) 56000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 320000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 630A

Fuse SQB3 screw M12 aR 1250V no ind 630A

Reference 2078031.630.0 - Manufacturer SIBA
Class aR
Rated current In (A) 630
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 120
Fixing dimensions M12
Melting I²t value (A²s) 83000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 480000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 700A

Fuse SQB3 screw M12 aR 1250V no ind 700A

Reference 2078031.700.0 - Manufacturer SIBA
Class aR
Rated current In (A) 700
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 131
Fixing dimensions M12
Melting I²t value (A²s) 113000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 640000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1250V no ind 750A

Fuse SQB3 screw M12 aR 1250V no ind 750A

Reference 2078031.750.0 - Manufacturer SIBA
Class aR
Rated current In (A) 750
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 133
Fixing dimensions M12
Melting I²t value (A²s) 169000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 957000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 screw M12 aR 1200V no ind 900A

Fuse SQB3 screw M12 aR 1200V no ind 900A

Reference 2078031.900.0 - Manufacturer SIBA
Class aR
Rated current In (A) 900
Rated Voltage Un AC (V) 1250
Dimension SBQ3
Applicable standards IEC, UL
Power loss (W) 140
Fixing dimensions M12
Melting I²t value (A²s) 236000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 1300000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 longM12 aR 1100V lateral switch adap 91mm 700A

Fuse SQB3 longM12 aR 1100V lateral switch adap 91mm 700A

Reference 2078152.700.0 - Manufacturer SIBA
Class aR
Rated current In (A) 700
Rated Voltage Un AC (V) 1100
Dimension SQB3
Applicable standards IEC
Power loss (W) 99
Fixing dimensions M12
Melting I²t value (A²s) 235000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 1200000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1000A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1000A

Reference 2078332.1000.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1000
Rated Voltage Un AC (V) 1000
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 150
Melting I²t value (A²s) 350000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 1900000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1100A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1100A

Reference 2078332.1100.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1100
Rated Voltage Un AC (V) 1000
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 174
Melting I²t value (A²s) 443000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2400000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1250A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1250A

Reference 2078332.1250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1250
Rated Voltage Un AC (V) 900
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 198
Melting I²t value (A²s) 652000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 3300000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1400A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 1400A

Reference 2078332.1400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1400
Rated Voltage Un AC (V) 900
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 210
Melting I²t value (A²s) 852000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 3900000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 315A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 315A

Reference 2078332.315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 1250
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 83
Melting I²t value (A²s) 11000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 60000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 350A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 350A

Reference 2078332.350.0 - Manufacturer SIBA
Class aR
Rated current In (A) 350
Rated Voltage Un AC (V) 1250
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 85
Melting I²t value (A²s) 15000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 90000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Fuse SQB3 US-UNC 1/2 1250V indic. flush end 400A

Fuse SQB3 US-UNC 1/2 1250V indic. flush end 400A

Reference 2078332.400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 400
Rated Voltage Un AC (V) 1250
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 92
Melting I²t value (A²s) 22000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 1/2
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 130000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Product available on request Ask for more information
Home
Product added to compare.
Product added to wishlist
