Fuse 36kV 67x537 back-up with striker 40A 120N

Reference 3001614.40.0 - Manufacturer SIBA

Rated current In (A)	40
Rated Voltage Un AC (V)	36000
Rated break.capacity I1 AC (A)	40000
Voltage of total I2t test	36000
Weight (g)	4200
Format	Cylindrical
Dimension	67x537mm
Pre-arcing I2t value (A2s)	2500
Total I2t value (A2s)	22700
Homologations	IEC
Power loss (W)	173

Price List €59.30/pc

Quantity

lock Datasheet

Fuse 7,2kV 53x292 TV with striker 5A 80N

Reference 3009813.5.0 - Manufacturer SIBA

Rated current In (A)	5
Rated Voltage Un AC (V)	7200
Rated break.capacity I1 AC (A)	80000
Voltage of total I2t test	6264
Weight (g)	1600
Format	Cylindrical
Dimension	53x292mm
Pre-arcing I2t value (A2s)	40
Total I2t value (A2s)	125
Homologations	IEC
Power loss (W)	5
Resistance (ohm)	0,141
Min breaking current (A)	40

Price List €373.76/pc

Quantity

lock Datasheet

Fuse 7,2kV 53x442 back-up with striker 3,15A 80N

Reference 3010813.3,15.0 - Manufacturer SIBA

Rated current In (A)	3,15
Rated Voltage Un AC (V)	7200
Rated break.capacity I1 AC (A)	80000
Voltage of total I2t test	6264
Weight (g)	2460
Format	Cylindrical
Dimension	67x442mm
Pre-arcing I2t value (A2s)	17
Total I2t value (A2s)	48
Homologations	IEC
Power loss (W)	5,5
Resistance (ohm)	0,42
Min breaking current (A)	24

Price List €84.78/pc

Quantity

lock Datasheet

Fuse 7,2kV 53x442 back-up with striker 4A 80N

Reference 3010813.4.0 - Manufacturer SIBA

Rated current In (A)	4
Rated Voltage Un AC (V)	7200
Rated break.capacity I1 AC (A)	80000
Voltage of total I2t test	6264
Format	Cylindrical
Dimension	67x442mm
Pre-arcing I2t value (A2s)	31
Total I2t value (A2s)	90
Homologations	IEC
Power loss (W)	7,2
Resistance (ohm)	0,31
Min breaking current (A)	32

Product available on request Ask for more information

Fuse 7,2kV 53x442 back-up with striker 50A 80N

Reference 3010813.50.0 - Manufacturer SIBA

Rated current In (A)	50
Rated Voltage Un AC (V)	7200
Rated break.capacity I1 AC (A)	80000
Voltage of total I2t test	6264
Weight (g)	2460
Format	Cylindrical
Dimension	67x442mm
Pre-arcing I2t value (A2s)	4600
Total I2t value (A2s)	42000
Homologations	IEC
Power loss (W)	41
Resistance (ohm)	0,012
Min breaking current (A)	170

Price List €98.15/pc

Quantity

lock Datasheet

Fuse 17,5kV 53x192 back-up with striker 3A 80N

Reference 3017913.3.0 - Manufacturer SIBA

Rated current In (A)	3
Rated Voltage Un AC (V)	17500
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	15225
Format	Cylindrical
Dimension	53x192mm
Pre-arcing I2t value (A2s)	16,5
Total I2t value (A2s)	42
Homologations	IEC
Power loss (W)	13
Resistance (ohm)	0,91
Min breaking current (A)	24

Product available on request Ask for more information

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 40A

Reference 302.935.93.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	40
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000
Pre-arcing I2t value (A2s)	230
Total I2t value (A2s)	840
Power loss (W)	7.2
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Distance (mm)	80
Series name	NR2B

Product available on request Ask for more information

B100 - Fuse 1000VDC aBat 750A - 132,7mm - Tin Plated

Reference 309.341.47.0.0 - Manufacturer FAULTRAP

Class	aBat
Rated current In (A)	750
Voltage of total I2t test	1000
Format	Screw fixing
Pre-arcing I2t value (A2s)	166000
Total I2t value (A2s)	500000
Power loss (W)	140
Fuses dimension	63,5x167
Rated Voltage Un DC (V)	1000
Rated break.capacity I1 DC (A)	100000
Time costant L/R (ms)	2
Series name	B100
Min breaking current (A)	7500

Product available on request Ask for more information

V103 - Fuse 10x38 1000VDC gPV 25A

Reference 309.409.87.0.0 - Manufacturer FAULTRAP

Class	gPV
Rated current In (A)	25
Voltage of total I2t test	1000
Format	Cylindrical
Pre-arcing I2t value (A2s)	125
Total I2t value (A2s)	1205
Power loss (W)	2,95
Fuses dimension	10x38
Rated Voltage Un DC (V)	1000
Rated break.capacity I1 DC (A)	20000
Series name	V103

Price List €21.09/pc

Quantity

lock Datasheet

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 63A

Reference 329.443.55.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	63
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000
Pre-arcing I2t value (A2s)	520
Total I2t value (A2s)	1900
Power loss (W)	9.5
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Distance (mm)	80
Series name	NR2B

Product available on request Ask for more information

NR2B - Fuse 00/80 aR 700VDC/690VAC with ind. w/o lug 25A

Reference 352.831.93.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	25
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000
Pre-arcing I2t value (A2s)	55
Total I2t value (A2s)	200
Power loss (W)	4.6
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Distance (mm)	80
Series name	NR2B

Product available on request Ask for more information

NR2B - Fuse 00/80 aR 700VDC/690VAC with ind. w/o lug 160A

Reference 382.074.88.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	160
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000
Pre-arcing I2t value (A2s)	3020
Total I2t value (A2s)	11100
Power loss (W)	37.5
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Distance (mm)	80
Series name	NR2B

Product available on request Ask for more information

B100 - Fuse 1000VDC aBat 630A - 132,7mm - Tin Plated

Reference 428.074.55.0.0 - Manufacturer FAULTRAP

Class	aBat
Rated current In (A)	630
Voltage of total I2t test	1000
Format	Screw fixing
Pre-arcing I2t value (A2s)	108000
Total I2t value (A2s)	324000
Power loss (W)	120
Fuses dimension	63,5x167
Rated Voltage Un DC (V)	1000
Rated break.capacity I1 DC (A)	100000
Time costant L/R (ms)	2
Series name	B100
Min breaking current (A)	6300

Product available on request Ask for more information

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 200A

Reference 456.865.11.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	200
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	5370
Total I2t value (A2s)	19600
Power loss (W)	48.5
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2B

Product available on request Ask for more information

NR2A - Fuse DIN000 80mm aR 700VDC/690VAC no ind 200A

Reference 456.980.23.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	200
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	5370
Total I2t value (A2s)	19600
Homologations	IEC
Power loss (W)	48,5
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2A

Price List €12.91/pc

Quantity

NR2A - Fuse DIN000 80mm aR 700VDC/690VAC no ind 100A

Reference 471.346.95.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	100
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	1340
Total I2t value (A2s)	5000
Homologations	IEC
Power loss (W)	19
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2A

Price List €11.63/pc

Quantity

lock Datasheet

Fuse BS 35x59 aR 240V (LMT) 300A

Reference 5005406.300.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	300
Rated Voltage Un AC (V)	240
Rated break.capacity I1 AC (A)	100000
Voltage of total I2t test	240
Weight (g)	150
Format	BS
Dimension	35x59mm
Pre-arcing I2t value (A2s)	7800
Total I2t value (A2s)	47000
Homologations	IEC
Power loss (W)	36

Price List €46.96/pc

Quantity

lock Datasheet

Fuse 150V DC 35x59mm aR BS 50A

Reference 5007838.50.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	50
Voltage of total I2t test	150
Format	BS
Dimension	35x59mm
Pre-arcing I2t value (A2s)	36000
Total I2t value (A2s)	38500
Homologations	UL
Power loss (W)	2,5
Rated Voltage Un DC (V)	150
Rated break.capacity I1 DC (A)	25000

Price List €32.54/pc

Quantity

Fuse 1100V DC 14x65 gPV IEC 60269-6 8A

Reference 5023526.8.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	8
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	5
Total I2t value (A2s)	22
Homologations	IEC
Power loss (W)	2,6
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Product available on request Ask for more information

Fuse 14x65 gPV 1100VDC plap contacts 10A

Reference 5023926.10.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	10
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	5
Total I2t value (A2s)	24
Homologations	IEC
Power loss (W)	0
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Product available on request Ask for more information

Fuse 14x65 gPV 1100VDC plap contacts 12A

Reference 5023926.12.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	12
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	13
Total I2t value (A2s)	62
Homologations	IEC
Power loss (W)	0
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Product available on request Ask for more information

Fuse 14x65 gPV 1100VDC plap contacts 16A

Reference 5023926.16.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	16
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	30
Total I2t value (A2s)	143
Homologations	IEC
Power loss (W)	0
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Product available on request Ask for more information

Fuse 14x65 gPV 1100VDC plap contacts 20A

Reference 5023926.20.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	20
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	53
Total I2t value (A2s)	143
Homologations	IEC
Power loss (W)	0
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Product available on request Ask for more information

Fuse 14x65 gPV 1000VDC plap contacts 30A

Reference 5023926.30.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	30
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	118
Total I2t value (A2s)	950
Homologations	IEC
Power loss (W)	0
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Price List €78.06/pc

Quantity

lock Datasheet

Fuse 14x65 gPV 1100VDC plap contacts 8A

Reference 5023926.8.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	8
Voltage of total I2t test	1100
Format	Cylindrical
Dimension	14x65mm
Pre-arcing I2t value (A2s)	5
Total I2t value (A2s)	22
Homologations	IEC
Power loss (W)	0
Rated Voltage Un DC (V)	1100
Rated break.capacity I1 DC (A)	30000

Product available on request Ask for more information

Fuse 27x60mm AC 480V 80mm

Reference 5053252.25.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	160
Rated Voltage Un AC (V)	480
Rated break.capacity I1 AC (A)	100000
Pre-arcing I2t value (A2s)	200000
Total I2t value (A2s)	350000
Homologations	IEC

Product available on request Ask for more information

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 25A

Reference 509.191.68.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	25
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	55
Total I2t value (A2s)	200
Power loss (W)	4.6
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2B

Product available on request Ask for more information

P103 - Fuse 550V DC EV with pins 50 AMP

Reference 515.316.40.0.0 - Manufacturer FAULTRAP

Rated current In (A)	50
Voltage of total I2t test	550
Dimension	10x38mm
Pre-arcing I2t value (A2s)	385
Total I2t value (A2s)	1200
Homologations	IEC
Power loss (W)	8,8
Rated Voltage Un DC (V)	550
Rated break.capacity I1 DC (A)	20000
Time costant L/R (ms)	2
Series name	P103

Product available on request Ask for more information

NR2B - Fuse 00/80 aR 690VAC with ind. w/o lug 400A

Reference 531.773.36.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	400
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	27210
Total I2t value (A2s)	156000
Power loss (W)	89
Time costant L/R (ms)	2
Series name	NR2B

Price List €25.57/pc

Quantity

P103 - Fuse 550V DC EV with pins 12 AMP

Reference 534.021.43.0.0 - Manufacturer FAULTRAP

Rated current In (A)	12
Voltage of total I2t test	550
Dimension	10x38mm
Pre-arcing I2t value (A2s)	9
Total I2t value (A2s)	45
Homologations	IEC
Power loss (W)	2,9
Rated Voltage Un DC (V)	550
Rated break.capacity I1 DC (A)	20000
Time costant L/R (ms)	2
Series name	P103

Product available on request Ask for more information

P103 - Fuse 550V DC EV with pins 25 AMP

Reference 539.088.71.0.0 - Manufacturer FAULTRAP

Rated current In (A)	25
Voltage of total I2t test	550
Dimension	10x38mm
Pre-arcing I2t value (A2s)	64
Total I2t value (A2s)	220
Homologations	IEC
Power loss (W)	3,95
Rated Voltage Un DC (V)	550
Rated break.capacity I1 DC (A)	20000
Time costant L/R (ms)	2
Series name	P103

Product available on request Ask for more information

NR2B - Fuse00/80 aR 700VDC/690VAC with ind. w/o lug 63A

Reference 555.565.09.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	63
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	520
Total I2t value (A2s)	1900
Power loss (W)	9.5
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2B

Product available on request Ask for more information

NR2B - Fuse 00/80 aR 690VAC with ind. w/o lug 350A

Reference 564.272.99.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	350
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	21500
Total I2t value (A2s)	110000
Power loss (W)	80
Time costant L/R (ms)	2
Series name	NR2B

Product available on request Ask for more information

B100 - Fuse 1000VDC aBat 750A - 152,7mm - Tin Plated

Reference 584.668.83.0.0 - Manufacturer FAULTRAP

Class	aBat
Rated current In (A)	750
Voltage of total I2t test	1000
Format	Screw fixing
Dimension	63,5x130,5mm
Pre-arcing I2t value (A2s)	166000
Total I2t value (A2s)	500000
Power loss (W)	140
Rated Voltage Un DC (V)	1000
Rated break.capacity I1 DC (A)	100000
Time costant L/R (ms)	2
Series name	B100
Min breaking current (A)	7500

Product available on request Ask for more information

NR2B - Fuse 00/80 aR 700VDC/690VAC with ind. w/o lug 50A

Reference 593.732.55.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	50
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	330
Total I2t value (A2s)	1200
Power loss (W)	9
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2B

Product available on request Ask for more information

NR2A - Fuse DIN000 80mm aR 700VDC/690VAC no ind 50A

Reference 600.836.00.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	50
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	700
Format	Screw fixing
Dimension	000-80mm
Pre-arcing I2t value (A2s)	330
Total I2t value (A2s)	1200
Homologations	IEC
Power loss (W)	9
Rated Voltage Un DC (V)	700
Rated break.capacity I1 DC (A)	30000
Time costant L/R (ms)	2
Series name	NR2A

Price List €10.58/pc

Quantity

lock Datasheet

4258 products

01
• • •
95
•
96
•
97
• • •
119

All Products

INFORMATIONS

ACCOUNT

CONTACT US

NEWSLETTER
