All Products

20PV22 - Fuse 2000VDC gPV 22x85mm inline aluminum 4AWG 40A

20PV22 - Fuse 2000VDC gPV 22x85mm inline aluminum 4AWG 40A

Reference 715.106.10.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 40
Applicable standards IEC
Power loss (W) 11.3
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 415
Fuse Connection/Terminal type In-line for aluminum cable
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 15A

20PV22 - Fuse 2000VDC gPV 22x85 15A

Reference 717.383.24.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 15
Applicable standards IEC
Power loss (W) 4.8
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 38
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
UR22 - Fuse 500V AC 22x58 cylindrical 135A

UR22 - Fuse 500V AC 22x58 cylindrical 135A

Reference 719.479.82.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 135
Rated Voltage Un AC (V) 550
Applicable standards IEC, UL
Power loss (W) 28,6
Series name UR22
Melting I²t value (A²s) 3640
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 17800
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
BP22 -Fuse 22x65mm cylindrical 50A

BP22 -Fuse 22x65mm cylindrical 50A

Reference 719.648.37.0.0 - Manufacturer FAULTRAP
Class gBat, gR
Rated current In (A) 50
Applicable standards IEC, UL
Power loss (W) 7,9
Rated Voltage Un DC (V) 1000
Series name BP22
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 22x65
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 737
Product available on request Ask for more information
20PV27 - Fuse 2000VDC gPV 27x85 inline 70A

20PV27 - Fuse 2000VDC gPV 27x85mm inline copper 6AWG 70A

Reference 720.065.13 .0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 70
Applicable standards IEC
Power loss (W) 20.2
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV27
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 27x85
Melting I²t value (A²s) 1400
Fuse Connection/Terminal type In-line for copper cable
Product available on request Ask for more information
Fuse DMI 5x20 FF 1000V ceramic 0,2A

Fuse DMI 5x20 FF 1000V ceramic 0,2A

Reference 7017640.0,2.0 - Manufacturer SIBA
Class FF
Rated current In (A) 0,2
Rated Voltage Un AC (V) 1000
Power loss (W) 0,2
Voltage drop (mV) 600
Fuse Dimension (mm) 5x20
Melting I²t value (A²s) 0,01
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 0,09
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1
Price List €12.84/pc
Quantity
Fuse DMI 5x20 FF 1000V ceramic 0,25A

Fuse DMI 5x20 FF 1000V ceramic 0,25A

Reference 7017640.0,25.0 - Manufacturer SIBA
Class FF
Rated current In (A) 0,25
Rated Voltage Un AC (V) 1000
Power loss (W) 0,2
Voltage drop (mV) 550
Fuse Dimension (mm) 5x20
Melting I²t value (A²s) 0,02
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 0,21
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 2
Price List €12.84/pc
Quantity
Fuse 5x20 FF 660VAC/DC 0,1A

Fuse 5x20 FF 660VAC/DC 0,1A

Reference 7018040.0,1.0 - Manufacturer SIBA
Class FF
Rated current In (A) 0,1
Rated Voltage Un AC (V) 660
Power loss (W) 0,1
Voltage drop (mV) 1000
Fuse Dimension (mm) 5x20
Melting I²t value (A²s) 0,0009
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 0,003
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 2
Price List €12.84/pc
Quantity
Fuse 5x20 FF 660VAC/DC 0,2A

Fuse 5x20 FF 660VAC/DC 0,2A

Reference 7018040.0,2.0 - Manufacturer SIBA
Class FF
Rated current In (A) 0,2
Rated Voltage Un AC (V) 660
Power loss (W) 0,2
Voltage drop (mV) 600
Fuse Dimension (mm) 5x20
Melting I²t value (A²s) 0,01
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 0,032
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 2
Price List €12.84/pc
Quantity
Fuse 5x20 FF 660VAC/DC 0,25A

Fuse 5x20 FF 660VAC/DC 0,25A

Reference 7018040.0,25.0 - Manufacturer SIBA
Class FF
Rated current In (A) 0,25
Rated Voltage Un AC (V) 660
Power loss (W) 0,2
Voltage drop (mV) 550
Fuse Dimension (mm) 5x20
Melting I²t value (A²s) 0,02
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 0,06
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 2
Price List €12.84/pc
Quantity
Fuse 5x20 FF 660VAC/DC 0,5A

Fuse 5x20 FF 660VAC/DC 0,5A

Reference 7018040.0,5.0 - Manufacturer SIBA
Class FF
Rated current In (A) 0,5
Rated Voltage Un AC (V) 660
Power loss (W) 0,3
Voltage drop (mV) 550
Fuse Dimension (mm) 5x20
Melting I²t value (A²s) 0,07
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 0,21
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 2
Price List €2.73/pc
Quantity
Fuse 8x65 F 1,5kV 0,4A

Fuse 8x65 F 1,5kV 0,4A

Reference 7018509.0,4.0 - Manufacturer SIBA
Class F
Rated current In (A) 0,4
Rated Voltage Un AC (V) 1500
Fuse Dimension (mm) 8x65
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Rated breaking capacity I1 AC (kA) 30000
Weight (gr) 9
Product available on request Ask for more information
Fuse 8x65 F 1,5kV 0,5A

Fuse 8x65 F 1,5kV 0,5A

Reference 7018509.0,5.0 - Manufacturer SIBA
Class F
Rated current In (A) 0,5
Rated Voltage Un AC (V) 1500
Fuse Dimension (mm) 8x65
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Rated breaking capacity I1 AC (kA) 30000
Weight (gr) 9
Price List €10.97/pc
Quantity
Fuse 8x65 F 1,5kV 2,5A

Fuse 8x65 F 1,5kV 2,5A

Reference 7018509.2,5.0 - Manufacturer SIBA
Class F
Rated current In (A) 2,5
Rated Voltage Un AC (V) 1500
Voltage drop (mV) 690
Fuse Dimension (mm) 8x65
Melting I²t value (A²s) 2,6
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 7,7
Rated breaking capacity I1 AC (kA) 30000
Weight (gr) 9
Product available on request Ask for more information
Fuse 8x65 F 1,5kV 2A

Fuse 8x65 F 1,5kV 2A

Reference 7018509.2.0 - Manufacturer SIBA
Class F
Rated current In (A) 2
Rated Voltage Un AC (V) 1500
Voltage drop (mV) 690
Fuse Dimension (mm) 8x65
Melting I²t value (A²s) 1,6
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 4,7
Rated breaking capacity I1 AC (kA) 30000
Weight (gr) 9
Price List €10.97/pc
Quantity
Fuse 8x65 F 1,5kV 3,15A

Fuse 8x65 F 1,5kV 3,15A

Reference 7018509.3,15.0 - Manufacturer SIBA
Class F
Rated current In (A) 3,15
Rated Voltage Un AC (V) 1500
Voltage drop (mV) 690
Fuse Dimension (mm) 8x65
Melting I²t value (A²s) 4,9
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 15
Rated breaking capacity I1 AC (kA) 30000
Weight (gr) 9
Price List €10.97/pc
Quantity
