20PV22 - Fuse 2000VDC gPV 22x85 50A

20PV22 - Fuse 2000VDC gPV 22x85 50A

Reference 774.105.69.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 50
Applicable standards IEC
Power loss (W) 12,7
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 815
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
Cover screw fixing for fuse holder 191100

Cover screw fixing for fuse holder 191100

Reference 7200105.0.0 - Manufacturer SIBA
Rated current In (A) 6,3
Fuse Dimension (mm) 5x20
Fuse Connection/Terminal type Cylindrical
Weight (gr) 4
Price List €1.85/pc
Quantity
Cover scew KM5 500V M9X1 VG88852

Cover scew KM5 500V M9X1 VG88852

Reference 7204402.0.0 - Manufacturer SIBA
Fuse Connection/Terminal type Diazed
Weight (gr) 6
Price List €30.71/pc
Quantity
A800 - Fuse 22x65 800V SPD protection 8/20 30kA 10/350 8kA

A800 - Fuse 22x65 800V SPD protection 8/20 30kA 10/350 8kA

Reference 721.081.58.0.0 - Manufacturer FAULTRAP
Rated Voltage Un AC (V) 800
Applicable standards IEC
Series name A800
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 36000
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 250000
Rated breaking capacity I1 AC (kA) 80
Price List €16.34/pc
Quantity
lock Datasheet
BPF1 - Fuse 1500VDC aBat d:50mm axial 168mm 400A

BPF1 - Fuse 1500VDC aBat d:50mm axial 168mm 400A

Reference 721.754.28.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 400
Applicable standards IEC
Power loss (W) 70,5
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name BPF1
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 50x168
Melting I²t value (A²s) 73750
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 258150
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 30A

20PV22 - Fuse 2000VDC gPV 22x85 30A

Reference 722.450.52.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 30
Applicable standards IEC
Power loss (W) 8.8
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 185
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
20PV10 - Fuse 2000VDC gPV 10x85 inline 2A

20PV10 - Fuse 2000VDC gPV 10x85 inline 2A

Reference 724.456.12.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 2
Applicable standards IEC
Power loss (W) 1,2
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV10
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 10x85
Melting I²t value (A²s) 2
Fuse Connection/Terminal type In-line for copper cable
Product available on request Ask for more information
DC22 - Fuse 1000VDC aBat 22x65mm bolted terminal 63A

DC22 - Fuse 1000VDC aBat 22x65mm bolted terminal 63A

Reference 725.960.68.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 63
Applicable standards IEC
Power loss (W) 12.5
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 1-3
Series name DC22
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 750
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 87
Total clearing I²t @Un DC (A²s) 3305
Price List €26.43/pc
Quantity
lock Datasheet
S276 - Fuse 27x60mm 500VAC gS PCB 125A

S276 - Fuse 27x60mm 500VAC gS PCB 125A

Reference 727.422.00.0.0 - Manufacturer FAULTRAP
Class gRL, gS
Rated current In (A) 125
Rated Voltage Un AC (V) 500
Applicable standards IEC, UL
Power loss (W) 10
Series name S276
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 10400
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 550
Total clearing I²t @Un AC (A²s) 55000
Product available on request Ask for more information
C315P - Fuse 150V AC aR 2800A size 3 with plate and microswi

C315P - Fuse 150V AC aR 2800A size 3 with plate and microswi

Reference 729.032.67.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 2800
Rated Voltage Un AC (V) 150
Applicable standards IEC
Power loss (W) 150
Series name C315P
Fixing dimensions M12
Melting I²t value (A²s) 1845000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 5535000
Rated breaking capacity I1 AC (kA) 230
Product available on request Ask for more information
NR2B - Fuse 00/80 aR 700VDC/690VAC with ind. w/o lug 315A

NR2B - Fuse 00/80 aR 700VDC/690VAC with ind. w/o lug 315A

Reference 732.361.29.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC, UL
Power loss (W) 70
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2B
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 16450
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 60000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
