Fuse DIN00 80mm 690V aR UL with indicator, w/o lug 400A

Fuse DIN00 80mm 690V aR UL with indicator, w/o lug 400A

Reference 2018920.400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 180
Rated Voltage Un AC (V) 660
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 200
Format Screw fixing
Dimension 00-80mm
Pre-arcing I2t value (A2s) 4200
Total I2t value (A2s) 23100
Power loss (W) 34
Price List €49.71/pc
Quantity
Fuse NH1 gR 690V top indicator 63A

Fuse NH1 gR 690V top indicator 63A

Reference 2021120.63.0 - Manufacturer SIBA
Class gR
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 100000
Voltage of total I2t test 690
Weight (g) 550
Format NH knife contact
Dimension NH1
Pre-arcing I2t value (A2s) 250
Total I2t value (A2s) 1800
Homologations IEC
Power loss (W) 14
Price List €49.97/pc
Quantity
lock Datasheet
Fuse NH2 aR 690V top indicator 250A

Fuse NH2 aR 690V top indicator 250A

Reference 2021220.250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 100000
Voltage of total I2t test 690
Weight (g) 520
Format NH knife contact
Dimension NH2
Pre-arcing I2t value (A2s) 5000
Total I2t value (A2s) 36000
Homologations IEC
Power loss (W) 71
Price List €66.25/pc
Quantity
lock Datasheet
Fuse 5x25 F 250V AC glass 0,8A 7000234.0,8

Fuse 5x25 F 250V AC glass 0,8A 7000234.0,8

Reference 171525.0,8.0 - Manufacturer SIBA
Class F
Rated current In (A) 0,8
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 50
Voltage of total I2t test 250
Weight (g) 1
Format Cylindrical
Dimension 5x25mm
Pre-arcing I2t value (A2s) 0,8
Power loss (W) 0,4
Voltage drop (mV) 160
Price List €1.07/pc
Quantity
lock Datasheet
Fuse 5x25 F 250V ceramic 8A 7001004.8

Fuse 5x25 F 250V ceramic 8A 7001004.8

Reference 171526.8.0 - Manufacturer SIBA
Class F
Rated current In (A) 8
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 1500
Voltage of total I2t test 250
Weight (g) 2
Format Cylindrical
Dimension 5x25mm
Pre-arcing I2t value (A2s) 100
Power loss (W) 3
Voltage drop (mV) 150
Price List €5.27/pc
Quantity
lock Datasheet
Fuse 5x20 M 250V glass 0,5A 7000102.0,5

Fuse 5x20 M 250V glass 0,5A 7000102.0,5

Reference 172000.0,5.0 - Manufacturer SIBA
Rated current In (A) 0,5
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 80
Voltage of total I2t test 250
Weight (g) 1
Format Cylindrical
Dimension 5x20mm
Pre-arcing I2t value (A2s) 0,9
Power loss (W) 0,2
Voltage drop (mV) 120
Price List €0.51/pc
Quantity
lock Datasheet
Fuse 5x20 T 250V glass + sand 15A 7000403.15

Fuse 5x20 T 250V glass + sand 15A 7000403.15

Reference 173100.15.0 - Manufacturer SIBA
Rated current In (A) 15
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 300
Voltage of total I2t test 250
Weight (g) 1
Format Cylindrical
Dimension 5x20mm
Pre-arcing I2t value (A2s) 1800
Power loss (W) 3,3
Voltage drop (mV) 80
Price List €0.28/pc
Quantity
Fuse 5x20 T 250V ceramic 0,5A 7000765.0,5

Fuse 5x20 T 250V ceramic 0,5A 7000765.0,5

Reference 179200.0,5.0 - Manufacturer SIBA
Rated current In (A) 0,5
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 1500
Voltage of total I2t test 250
Format Cylindrical
Dimension 5x20mm
Pre-arcing I2t value (A2s) 0,35
Homologations UL
Power loss (W) 0,4
Voltage drop (mV) 350
Price List €0.77/pc
Quantity
lock Datasheet
Fuse 3kV 8x85 F 1,25A 7003509.1,25

Fuse 3kV 8x85 F 1,25A 7003509.1,25

Reference 185000.1,25.0 - Manufacturer SIBA
Class F
Rated current In (A) 1,25
Rated Voltage Un AC (V) 3000
Rated break.capacity I1 AC (A) 35
Weight (g) 9
Format Cylindrical
Dimension 8x85mm
Pre-arcing I2t value (A2s) 0,45
Voltage drop (mV) 1000
Price List €36.41/pc
Quantity
lock Datasheet
Fuse 6kV 8x120 0,032A 7003810.0,032

Fuse 6kV 8x120 0,032A 7003810.0,032

Reference 186000.0,032.0 - Manufacturer SIBA
Rated current In (A) 0,032
Rated Voltage Un AC (V) 6000
Rated break.capacity I1 AC (A) 35
Weight (g) 6
Format Cylindrical
Dimension 8x120mm
Pre-arcing I2t value (A2s) 0,0003
Voltage drop (mV) 6000
Price List €18.47/pc
Quantity
lock Datasheet
Fuse 6kV 8x120 0,25A 7003810.0,25

Fuse 6kV 8x120 0,25A 7003810.0,25

Reference 186000.0,25.0 - Manufacturer SIBA
Class F
Rated current In (A) 0,25
Rated Voltage Un AC (V) 6000
Rated break.capacity I1 AC (A) 35
Weight (g) 10
Format Cylindrical
Dimension 8x120mm
Pre-arcing I2t value (A2s) 0,02
Voltage drop (mV) 14000
Price List €17.44/pc
Quantity
lock Datasheet
Fuse 6,3x32 F 250V glass 8A 7005960.8

Fuse 6,3x32 F 250V glass 8A 7005960.8

Reference 189000.8.0 - Manufacturer SIBA
Class F
Rated current In (A) 8
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 80
Voltage of total I2t test 250
Weight (g) 3
Format Cylindrical
Dimension 6,3x32mm
Pre-arcing I2t value (A2s) 240
Homologations IEC
Power loss (W) 2
Voltage drop (mV) 160
Price List €0.28/pc
Quantity
lock Datasheet
Fuse 5x20 TT 250V glass 0,63A 7000181.0,63

Fuse 5x20 TT 250V glass 0,63A 7000181.0,63

Reference 190000.0,63.0 - Manufacturer SIBA
Rated current In (A) 0,63
Rated Voltage Un AC (V) 250
Rated break.capacity I1 AC (A) 35
Voltage of total I2t test 250
Weight (g) 1
Format Cylindrical
Dimension 5x20mm
Pre-arcing I2t value (A2s) 10
Voltage drop (mV) 400
Price List €1.14/pc
Quantity
lock Datasheet
Fuse gB NH00 500V 63A

Fuse gB NH00 500V 63A

Reference 2000103.63.0 - Manufacturer SIBA
Class gB
Rated current In (A) 63
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 500
Weight (g) 170
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 1100
Total I2t value (A2s) 4400
Power loss (W) 6,4
Price List €49.80/pc
Quantity
lock Datasheet
Fuse NH00 TY-gG 500V 25A

Fuse NH00 TY-gG 500V 25A

Reference 2000116.25.0 - Manufacturer SIBA
Class gG
Rated current In (A) 25
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 318
Weight (g) 160
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 1500
Total I2t value (A2s) 2700
Homologations IEC
Power loss (W) 2,4
Product available on request Ask for more information
Fuse NH0 gG 500V double indicator 160A

Fuse NH0 gG 500V double indicator 160A

Reference 2000213.160.0 - Manufacturer SIBA
Class gG
Rated current In (A) 160
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 440
Weight (g) 267
Format NH knife contact
Dimension NH0
Pre-arcing I2t value (A2s) 78500
Total I2t value (A2s) 226600
Homologations IEC
Power loss (W) 12,8
Time costant L/R (ms) 15
Price List €9.03/pc
Quantity
lock Datasheet
Fuse NH0 TY-gG 500V 35A

Fuse NH0 TY-gG 500V 35A

Reference 2000216.35.0 - Manufacturer SIBA
Class gG
Rated current In (A) 35
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 318
Weight (g) 230
Format NH knife contact
Dimension NH0
Pre-arcing I2t value (A2s) 3400
Total I2t value (A2s) 5900
Homologations IEC
Power loss (W) 3,9
Product available on request Ask for more information
Fuse NH3 TY-gG 500V 125A

Fuse NH3 TY-gG 500V 125A

Reference 2000516.125.0 - Manufacturer SIBA
Class gG
Rated current In (A) 125
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 318
Weight (g) 870
Format NH knife contact
Dimension NH3
Pre-arcing I2t value (A2s) 36200
Total I2t value (A2s) 62000
Homologations IEC
Power loss (W) 9,6
Product available on request Ask for more information
Fuse NH00 gG 500V with striker 16A

Fuse NH00 gG 500V with striker 16A

Reference 2000713.16.0 - Manufacturer SIBA
Class gG
Rated current In (A) 16
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 440
Weight (g) 240
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 420
Total I2t value (A2s) 810
Homologations IEC
Power loss (W) 3,6
Price List €38.05/pc
Quantity
lock Datasheet
Fuse NH00 gG 500V with striker 35A

Fuse NH00 gG 500V with striker 35A

Reference 2000713.35.0 - Manufacturer SIBA
Class gG
Rated current In (A) 35
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 440
Weight (g) 190
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 3100
Total I2t value (A2s) 7610
Homologations IEC
Power loss (W) 3,8
Price List €38.03/pc
Quantity
lock Datasheet
Fuse NH1 gG 500V with striker 50A

Fuse NH1 gG 500V with striker 50A

Reference 2000913.50.0 - Manufacturer SIBA
Class gG
Rated current In (A) 50
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 440
Weight (g) 410
Format NH knife contact
Dimension NH1
Pre-arcing I2t value (A2s) 5900
Total I2t value (A2s) 13600
Homologations IEC
Power loss (W) 5,1
Price List €201.37/pc
Quantity
lock Datasheet
Fuse NH3 gG 500V with striker 425A

Fuse NH3 gG 500V with striker 425A

Reference 2001113.425.0 - Manufacturer SIBA
Class gG
Rated current In (A) 425
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 440
Weight (g) 920
Format NH knife contact
Dimension NH3
Homologations IEC
Price List €479.87/pc
Quantity
lock Datasheet
Fuse DIN00 80mm 690V gR UL with indicator, w/o lug 16A

Fuse DIN00 80mm 690V gR UL with indicator, w/o lug 16A

Reference 2018920.16.0 - Manufacturer SIBA
Rated current In (A) 180
Rated Voltage Un AC (V) 660
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 200
Format Screw fixing
Dimension 00-80mm
Pre-arcing I2t value (A2s) 4200
Total I2t value (A2s) 23100
Power loss (W) 34
Price List €20.98/pc
Quantity
Fuse NH4 screw fixing aM 690V top indicator 400A

Fuse NH4 screw fixing aM 690V top indicator 400A

Reference 2022508.400.0 - Manufacturer SIBA
Class aM
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 500
Weight (g) 2250
Format NH knife contact
Dimension NH4
Pre-arcing I2t value (A2s) 623000
Total I2t value (A2s) 2350000
Homologations IEC
Power loss (W) 31
Price List €124.51/pc
Quantity
lock Datasheet
