20PV27 - Fuse 2000VDC gPV 27x85mm inline aluminum 2AWG 75A

20PV27 - Fuse 2000VDC gPV 27x85mm inline aluminum 2AWG 75A

Reference 393.313.98.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 75
Applicable standards IEC
Power loss (W) 19.7
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV27
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 27x85
Melting I²t value (A²s) 1900
Fuse Connection/Terminal type In-line for aluminum cable
Product available on request Ask for more information
UR22 - Fuse 690V AC 22x58 cylindrical 63A

UR22 - Fuse 690V AC 22x58 cylindrical 63A

Reference 394.522.47.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 63
Rated Voltage Un AC (V) 550
Applicable standards IEC, UL
Power loss (W) 13,4
Series name UR22
Melting I²t value (A²s) 540
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 2370
Rated breaking capacity I1 AC (kA) 200
Price List €16.88/pc
Quantity
lock Datasheet
B500 - Fuse 1500VDC aBat 4xM10 with micro adapter 1800A

B500 - Fuse 1500VDC aBat 4xM10 with micro adapter 1800A

Reference 395.882.51.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1800
Applicable standards IEC
Power loss (W) 430
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name B500
Rated breaking capacity I1 DC (kA) 250000
Fuse Dimension (mm) 103x144
Fixing dimensions M10
Melting I²t value (A²s) 1615000
Minimum breaking current (A) 19800
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 8720000
Product available on request Ask for more information
Fuse NH0 gG 500V with striker 32A

Fuse NH0 gG 500V with striker 32A

Reference 395135.0.0 - Manufacturer DF
Class gG
Rated current In (A) 32
Rated Voltage Un AC (V) 500
Dimension NH0
Applicable standards IEC
Power loss (W) 4,5
Melting I²t value (A²s) 2779
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 6475
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 325
Price List €14.39/pc
Quantity
Fuse NH0 gG 500V with striker 35A

Fuse NH0 gG 500V with striker 35A

Reference 395140.0.0 - Manufacturer DF
Rated current In (A) 35
Rated Voltage Un AC (V) 500
Dimension NH0
Applicable standards IEC
Power loss (W) 4,8
Melting I²t value (A²s) 3190
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 7433
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 325
Price List €14.39/pc
Quantity
Fuse NH0 gG 500V with striker 40A

Fuse NH0 gG 500V with striker 40A

Reference 395145.0.0 - Manufacturer DF
Class gG
Rated current In (A) 40
Rated Voltage Un AC (V) 500
Dimension NH0
Applicable standards IEC
Power loss (W) 5,2
Melting I²t value (A²s) 4595
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 10700
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 325
Price List €14.39/pc
Quantity
Fuse NH0 gG 500V with striker 50A

Fuse NH0 gG 500V with striker 50A

Reference 395150.0.0 - Manufacturer DF
Class gG
Rated current In (A) 50
Rated Voltage Un AC (V) 500
Dimension NH0
Applicable standards IEC
Power loss (W) 6,7
Melting I²t value (A²s) 5600
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 17500
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 325
Price List €14.46/pc
Quantity
Fuse NH0 gG 500V with striker 63A

Fuse NH0 gG 500V with striker 63A

Reference 395155.0.0 - Manufacturer DF
Class gG
Rated current In (A) 63
Rated Voltage Un AC (V) 500
Dimension NH0
Applicable standards IEC
Power loss (W) 7
Melting I²t value (A²s) 5700
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 22000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 325
Price List €14.46/pc
Quantity
