Fuse 1500V DC gR NH3L 315A

Fuse 1500V DC gR NH3L 315A

Reference 2024336.315.0 - Manufacturer SIBA
Class gBat, gR
Rated current In (A) 315
Dimension NH3L
Applicable standards IEC, UL
Power loss (W) 55
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 260000
Melting I²t value (A²s) 56000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 392000
Product available on request Ask for more information
Fuse 1500V DC gR NH3L 350A

Fuse 1500V DC gR NH3L 350A

Reference 2024336.350.0 - Manufacturer SIBA
Class gBat, gR
Rated current In (A) 350
Dimension NH3L
Applicable standards IEC, UL
Power loss (W) 60
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 260000
Melting I²t value (A²s) 77000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 540000
Price List €415.91/pc
Quantity
lock Datasheet
Fuse 1500V DC gR NH3L 400A

Fuse 1500V DC gR NH3L 400A

Reference 2024336.400.0 - Manufacturer SIBA
Class gBat, gR
Rated current In (A) 400
Dimension NH3L
Applicable standards IEC, UL
Power loss (W) 66
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 260000
Melting I²t value (A²s) 106000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 745000
Price List €95.02/pc
Quantity
lock Datasheet
Fuse 1500V DC gR NH3L 450A

Fuse 1500V DC gR NH3L 450A

Reference 2024336.450.0 - Manufacturer SIBA
Class gBat, gR
Rated current In (A) 450
Dimension NH3L
Applicable standards IEC, UL
Power loss (W) 74
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 260000
Melting I²t value (A²s) 153000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 1075000
Product available on request Ask for more information
Fuse 1500V DC gR NH3L 500A

Fuse 1500V DC gR NH3L 500A

Reference 2024336.500.0 - Manufacturer SIBA
Class gBat, gR
Rated current In (A) 500
Dimension NH3L
Applicable standards IEC, UL
Power loss (W) 82
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 260000
Melting I²t value (A²s) 189000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 1325000
Product available on request Ask for more information
Fuse NH4 screw fixing aM 690V top indicator 500A

Fuse NH4 screw fixing aM 690V top indicator 500A

Reference 2022508.500.0 - Manufacturer SIBA
Class aM
Rated current In (A) 500
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 40
Melting I²t value (A²s) 829000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 3150000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €131.09/pc
Quantity
lock Datasheet
Fuse NH4 screw fixing aM 690V top indicator 630A

Fuse NH4 screw fixing aM 690V top indicator 630A

Reference 2022508.630.0 - Manufacturer SIBA
Class aM
Rated current In (A) 630
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 48
Melting I²t value (A²s) 1470000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 5600000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €114.15/pc
Quantity
lock Datasheet
Fuse NH4 screw fixing aM 690V top indicator 800A

Fuse NH4 screw fixing aM 690V top indicator 800A

Reference 2022508.800.0 - Manufacturer SIBA
Class aM
Rated current In (A) 800
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 58
Melting I²t value (A²s) 2780000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 10500000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €118.51/pc
Quantity
lock Datasheet
Fuse NH4 screw fixing gG 690V top indicator 400A

Fuse NH4 screw fixing gG 690V top indicator 400A

Reference 2022513.400.0 - Manufacturer SIBA
Class aM
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 32
Melting I²t value (A²s) 859000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 1900000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €212.58/pc
Quantity
lock Datasheet
Fuse NH4 screw fixing gG 690V top indicator 500A

Fuse NH4 screw fixing gG 690V top indicator 500A

Reference 2022513.500.0 - Manufacturer SIBA
Class aM
Rated current In (A) 500
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 42
Melting I²t value (A²s) 1130000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 2400000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €212.66/pc
Quantity
lock Datasheet
Fuse NH4 screw fixing gG 690V top indicator 630A

Fuse NH4 screw fixing gG 690V top indicator 630A

Reference 2022513.630.0 - Manufacturer SIBA
Class aM
Rated current In (A) 630
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 51
Melting I²t value (A²s) 1950000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 4000000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €220.15/pc
Quantity
lock Datasheet
Fuse NH4 screw fixing gG 690V top indicator 800A

Fuse NH4 screw fixing gG 690V top indicator 800A

Reference 2022513.800.0 - Manufacturer SIBA
Class aM
Rated current In (A) 800
Rated Voltage Un AC (V) 690
Dimension NH4
Applicable standards IEC
Power loss (W) 65
Melting I²t value (A²s) 3700000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 11300000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2250
Price List €121.14/pc
Quantity
lock Datasheet
Fuse NH4L screw fixing gG 690V double indicator 400A

Fuse NH4L screw fixing gG 690V double indicator 400A

Reference 2022613.1000.0 - Manufacturer SIBA
Class aM
Rated current In (A) 1000
Rated Voltage Un AC (V) 690
Dimension NH4L
Applicable standards IEC
Power loss (W) 95
Melting I²t value (A²s) 5550000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 13000000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 4040
Price List €180.76/pc
Quantity
lock Datasheet
Fuse NH4a aM 690V top indicator 1000A

Fuse NH4a aM 690V top indicator 1000A

Reference 2022708.1000.0 - Manufacturer SIBA
Class aM
Rated current In (A) 1000
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 78
Melting I²t value (A²s) 4510000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 17000000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €159.41/pc
Quantity
lock Datasheet
Fuse NH4a aM 690V top indicator 1250A

Fuse NH4a aM 690V top indicator 1250A

Reference 2022708.1250.0 - Manufacturer SIBA
Class aM
Rated current In (A) 1250
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 100
Melting I²t value (A²s) 7800000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 29000000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €160.87/pc
Quantity
lock Datasheet
Fuse NH4a aM 690V top indicator 400A

Fuse NH4a aM 690V top indicator 400A

Reference 2022708.400.0 - Manufacturer SIBA
Class aM
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 34
Melting I²t value (A²s) 623000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 2350000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €1,019.10/pc
Quantity
lock Datasheet
Fuse NH4a aM 690V top indicator 500A

Fuse NH4a aM 690V top indicator 500A

Reference 2022708.500.0 - Manufacturer SIBA
Class aM
Rated current In (A) 500
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 44
Melting I²t value (A²s) 829000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 3150000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €134.33/pc
Quantity
lock Datasheet
Fuse NH4a aM 690V top indicator 630A

Fuse NH4a aM 690V top indicator 630A

Reference 2022708.630.0 - Manufacturer SIBA
Class aM
Rated current In (A) 630
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 53
Melting I²t value (A²s) 1470000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 5600000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €159.12/pc
Quantity
lock Datasheet
Fuse NH4a aM 690V top indicator 800A

Fuse NH4a aM 690V top indicator 800A

Reference 2022708.800.0 - Manufacturer SIBA
Class aM
Rated current In (A) 800
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 64
Melting I²t value (A²s) 2780000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 10500000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €164.77/pc
Quantity
lock Datasheet
Fuse NH4a gG 690V top indicator 1000A

Fuse NH4a gG 690V top indicator 1000A

Reference 2022713.1000.0 - Manufacturer SIBA
Class aM
Rated current In (A) 1000
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 95
Melting I²t value (A²s) 5550000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 13000000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2800
Price List €142.70/pc
Quantity
lock Datasheet
Fuse NH4a gG 690V top indicator 400A

Fuse NH4a gG 690V top indicator 400A

Reference 2022713.400.0 - Manufacturer SIBA
Class aM
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 30
Melting I²t value (A²s) 800000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 1900000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €198.05/pc
Quantity
lock Datasheet
Fuse NH4a gG 690V top indicator 500A

Fuse NH4a gG 690V top indicator 500A

Reference 2022713.500.0 - Manufacturer SIBA
Class aM
Rated current In (A) 500
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 40
Melting I²t value (A²s) 1100000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 2400000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2630
Price List €198.12/pc
Quantity
lock Datasheet
Fuse NH4a gG 690V top indicator 630A

Fuse NH4a gG 690V top indicator 630A

Reference 2022713.630.0 - Manufacturer SIBA
Class aM
Rated current In (A) 630
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 50
Melting I²t value (A²s) 1700000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 3950000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2620
Price List €142.52/pc
Quantity
lock Datasheet
Fuse NH4a gG 690V top indicator 800A

Fuse NH4a gG 690V top indicator 800A

Reference 2022713.800.0 - Manufacturer SIBA
Class aM
Rated current In (A) 800
Rated Voltage Un AC (V) 690
Dimension NH4a
Applicable standards IEC
Power loss (W) 70
Melting I²t value (A²s) 3000000
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 7000000
Rated breaking capacity I1 AC (kA) 120000
Weight (gr) 2600
Price List €138.99/pc
Quantity
lock Datasheet
Filter by
Manufacturer
Series name
Class
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Rated insultaion voltage AC (V)
Rated insulated voltage DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
