All Products

Showing 13501-13536 of 14560 item(s)

Fuse BR Motors 7,2kV 403mm 150A

Reference 3045955.5R.0 - Manufacturer SIBA

Class	HH Motors
Rated current In (A)	150
Rated Voltage Un AC (V)	7200
Applicable standards	IEC
Power loss (W)	96
Fuse Dimension (mm)	76x403
Melting I²t value (A²s)	37600
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	6300
Total clearing I²t @Un AC (A²s)	215000
Rated breaking capacity I1 AC (kA)	50000

Product available on request Ask for more information

Fuse BR Motors 7,2kV 403mm 170A

Reference 3045955.6R.0 - Manufacturer SIBA

Class	HH Motors
Rated current In (A)	170
Rated Voltage Un AC (V)	7200
Applicable standards	IEC
Power loss (W)	105
Fuse Dimension (mm)	76x403
Melting I²t value (A²s)	49000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	6300
Total clearing I²t @Un AC (A²s)	269000
Rated breaking capacity I1 AC (kA)	50000

Product available on request Ask for more information

Fuse BR Motors 7,2kV 403mm 200A

Reference 3045955.9R.0 - Manufacturer SIBA

Class	HH Motors
Rated current In (A)	200
Rated Voltage Un AC (V)	7200
Applicable standards	IEC
Power loss (W)	102
Fuse Dimension (mm)	76x403
Melting I²t value (A²s)	100400
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	6300
Total clearing I²t @Un AC (A²s)	562000
Rated breaking capacity I1 AC (kA)	50000

Product available on request Ask for more information

Fuse BR Motors 7,2kV 403mm 390A

Reference 3046055.18R.0 - Manufacturer SIBA

Class	HH Motors
Rated current In (A)	390
Rated Voltage Un AC (V)	7200
Applicable standards	IEC
Power loss (W)	190
Fuse Dimension (mm)	76x403
Melting I²t value (A²s)	485000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	6300
Total clearing I²t @Un AC (A²s)	2450000
Rated breaking capacity I1 AC (kA)	50000
Weight (gr)	8720

Product available on request Ask for more information

Fuse BR Motors 7,2kV 403mm 650A

Reference 3046155.36R.0 - Manufacturer SIBA

Class	HH Motors
Rated current In (A)	650
Rated Voltage Un AC (V)	7200
Applicable standards	IEC
Power loss (W)	284
Fuse Dimension (mm)	76x403
Melting I²t value (A²s)	1527000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	6300
Total clearing I²t @Un AC (A²s)	7635000
Rated breaking capacity I1 AC (kA)	50000
Weight (gr)	8720

Product available on request Ask for more information

Fuse 12kV 66x442mm back-up oil applications +striker 80A 80N

Reference 3046413.80.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	80
Rated Voltage Un AC (V)	12000
Applicable standards	IEC
Fuse Dimension (mm)	67x442
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	12000
Weight (gr)	3760

Product available on request Ask for more information

Fuse 24kV 67x442 back-up oil applications +striker 50A 80N

Reference 3046513.50.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	50
Rated Voltage Un AC (V)	24000
Applicable standards	IEC
Power loss (W)	108
Rated breaking capacity I1 DC (kA)	63000
Fuse Dimension (mm)	67x442
Melting I²t value (A²s)	5700
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	24000
Total clearing I²t @Un AC (A²s)	33000
Weight (gr)	3720

Product available on request Ask for more information

Fuse 36kV 53x442 back-up oil applications +striker 6,3A 80N

Reference 3046613.6,3.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	6,3
Rated Voltage Un AC (V)	36000
Applicable standards	IEC
Power loss (W)	44
Fuse Dimension (mm)	53x442
Melting I²t value (A²s)	45
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	36000
Total clearing I²t @Un AC (A²s)	360
Rated breaking capacity I1 AC (kA)	40000

Product available on request Ask for more information

Fuse 36kV 85x537 back-up with striker 80N 63A

Reference 3047213.63.0 - Manufacturer SIBA

Rated current In (A)

Product available on request Ask for more information

Fuse 36kV 85x537 back-up with striker 80N 80A

Reference 3047213.80.0 - Manufacturer SIBA

Rated current In (A)

Product available on request Ask for more information

672GP05 Termianl block 600V 30A 5 poles

Reference 305.0.0 - Manufacturer MARATHON

Rated current In (A)	30
Rated Voltage Un AC (V)	600
Applicable standards	UL
Number of connections	5

Price List €23.56/pc

Quantity

lock Datasheet

Fuse 40,5kV 254x63,5 back-up BV 0,5A

Reference 3050311.0,5.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	0,5
Rated Voltage Un AC (V)	40500
Applicable standards	IEC
Power loss (W)	7
Fuse Dimension (mm)	254x63,5
Melting I²t value (A²s)	0,225
Fuse Connection/Terminal type	Cylindrical
Weight (gr)	1940

Product available on request Ask for more information

Fuse 40,5kV 254x63,5 back-up BV 0,5A

Reference 3050411.0,5.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	0,5
Rated Voltage Un AC (V)	40500
Applicable standards	IEC
Power loss (W)	6,5
Fuse Dimension (mm)	254x63,5
Melting I²t value (A²s)	0,225
Fuse Connection/Terminal type	Cylindrical
Weight (gr)	1940

Product available on request Ask for more information

Fuse 40,5kV 254x63,5 back-up BV 1A

Reference 3050411.1.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	1
Rated Voltage Un AC (V)	40500
Applicable standards	IEC
Power loss (W)	9,2
Fuse Dimension (mm)	254x63,5
Melting I²t value (A²s)	1,1
Fuse Connection/Terminal type	Cylindrical
Weight (gr)	1940

Product available on request Ask for more information

Fuse 24kV 39,6x327 M8 TV rough ceramic surface 2A

Reference 3050711.2.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	2
Rated Voltage Un AC (V)	36000
Applicable standards	IEC
Power loss (W)	15
Fuse Dimension (mm)	40x340
Melting I²t value (A²s)	3,2
Fuse Connection/Terminal type	BS
Voltage of total clearing I2t test	24000
Total clearing I²t @Un AC (A²s)	9,9
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 24kV 39,6x327 M8 TV rough ceramic surface 3A

Reference 3050711.3.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	3
Rated Voltage Un AC (V)	36000
Applicable standards	IEC
Power loss (W)	17
Fuse Dimension (mm)	40x340
Melting I²t value (A²s)	16,1
Fuse Connection/Terminal type	BS
Voltage of total clearing I2t test	24000
Total clearing I²t @Un AC (A²s)	47,8
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 24kV 39,6x327 M8 TV rough ceramic surface 4A

Reference 3050711.4.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	4
Rated Voltage Un AC (V)	36000
Applicable standards	IEC
Power loss (W)	26
Fuse Dimension (mm)	40x340
Melting I²t value (A²s)	28,9
Fuse Connection/Terminal type	BS
Voltage of total clearing I2t test	24000
Total clearing I²t @Un AC (A²s)	85,3
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 24kV 39,6x327 M8 TV rough ceramic surface 5A

Reference 3050711.5.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	5
Rated Voltage Un AC (V)	36000
Applicable standards	IEC
Power loss (W)	31
Fuse Dimension (mm)	40x340
Melting I²t value (A²s)	40,9
Fuse Connection/Terminal type	BS
Voltage of total clearing I2t test	24000
Total clearing I²t @Un AC (A²s)	120,7
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 5,5kV 63,5x359 screw M12 capacitor protection

Reference 3051026.160.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	160
Rated Voltage Un AC (V)	5500
Applicable standards	IEC
Power loss (W)	105
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	90000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	5500
Total clearing I²t @Un AC (A²s)	570000
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 5,5kV 63,5x359 screw M12 capacitor protection

Reference 3051026.200.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	200
Rated Voltage Un AC (V)	5500
Applicable standards	IEC
Power loss (W)	132
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	230000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	5500
Total clearing I²t @Un AC (A²s)	704000
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 10A

Reference 3051126.10.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	10
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	25
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	75
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	500
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 16A

Reference 3051126.16.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	16
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	22
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	250
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	1800
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 20A

Reference 3051126.20.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	20
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	24
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	640
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	4300
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 25A

Reference 3051126.25.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	25
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	28
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	1050
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	6700
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 31,5A

Reference 3051126.31,5.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	31,5
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	35
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	1700
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	10800
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 40A

Reference 3051126.40.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	40
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	45
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	2900
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	17100
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x254 screw M12 capacitor protection 6,3A

Reference 3051126.6,3.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	6,3
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	18
Fuse Dimension (mm)	63,5x254
Fixing dimensions	M12
Melting I²t value (A²s)	45
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	330
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x359 screw M12 capacitor protection 100A

Reference 3051226.100.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	100
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	95
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	33000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	189000
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x359 screw M12 capacitor protection 125A

Reference 3051226.125.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	125
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	136
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	47000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	351000
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x359 screw M12 capacitor protection 50A

Reference 3051226.50.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	50
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	52
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	5700
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	29700
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x359 screw M12 capacitor protection 63A

Reference 3051226.63.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	63
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	64
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	10700
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	59400
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 8,3kV 63,5x359 screw M12 capacitor protection 80A

Reference 3051226.80.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	80
Rated Voltage Un AC (V)	8300
Applicable standards	IEC
Power loss (W)	73
Fuse Dimension (mm)	63,5x359
Fixing dimensions	M12
Melting I²t value (A²s)	21000
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	8300
Total clearing I²t @Un AC (A²s)	126000
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 7,2kV 254x63,5 back-up BV 1A

Reference 3051311.1.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	1
Rated Voltage Un AC (V)	7200
Applicable standards	IEC
Power loss (W)	2,8
Fuse Dimension (mm)	254x63,5
Melting I²t value (A²s)	1,1
Fuse Connection/Terminal type	Cylindrical
Weight (gr)	1940

Product available on request Ask for more information

Fuse 12kV 254x63,5 back-up BV 1A

Reference 3051411.1.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	1
Rated Voltage Un AC (V)	12000
Applicable standards	IEC
Power loss (W)	5
Fuse Dimension (mm)	254x63,5
Melting I²t value (A²s)	1,1
Fuse Connection/Terminal type	Cylindrical
Weight (gr)	1940

Product available on request Ask for more information

Fuse 15,5kV 39,6x203mm unglazed ceramic M10 3A

Reference 3051711.3.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	3
Rated Voltage Un AC (V)	15500
Applicable standards	IEC
Power loss (W)	15
Fuse Dimension (mm)	39,6x203
Melting I²t value (A²s)	16
Fuse Connection/Terminal type	BS
Voltage of total clearing I2t test	13485
Total clearing I²t @Un AC (A²s)	48
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

Fuse 15,5kV 39,6x203mm unglazed ceramic M11 4A

Reference 3051711.4.0 - Manufacturer SIBA

Class	HH Back up
Rated current In (A)	4
Rated Voltage Un AC (V)	15500
Applicable standards	IEC
Power loss (W)	20
Fuse Dimension (mm)	39,6x203
Melting I²t value (A²s)	29
Fuse Connection/Terminal type	BS
Voltage of total clearing I2t test	13485
Total clearing I²t @Un AC (A²s)	85
Rated breaking capacity I1 AC (kA)	63000

Product available on request Ask for more information

14560 products

01
• • •
375
•
376
•
377
• • •
405

All Products

INFORMATIONS

ACCOUNT

CONTACT US

NEWSLETTER
