All Products

Partition wall NH3L

Partition wall NH3L

Reference 326635.0.0 - Manufacturer DF
Price List €11.79/pc
Quantity
C100 - Fuse 690V aR size 1 M8 80A

C100 - Fuse 690V aR size 1 M8 80A

Reference 328.484.93.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 12
Fixing dimensions M8
Melting I²t value (A²s) 185
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 1250
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Storage holders 12kV

Storage holders 12kV

Reference 3300401.0.0 - Manufacturer SIBA
Fuse Connection/Terminal type Cylindrical
Fixing connection centres (mm) 292
Weight (gr) 1040
Price List €238.93/pc
Quantity
Storage holders 24kV

Storage holders 24kV

Reference 3300601.0.0 - Manufacturer SIBA
Fuse Connection/Terminal type Cylindrical
Weight (gr) 1420
Price List €320.06/pc
Quantity
Storage holders 36kV 3x537mm

Storage holders 36kV 3x537mm

Reference 3300801.0.0 - Manufacturer SIBA
Fuse Connection/Terminal type Cylindrical
Weight (gr) 2970
Price List €485.78/pc
Quantity
Fuse holder 17,5kV 192mm indoor up to 200A

Fuse holder 17,5kV 192mm indoor up to 200A

Reference 3117902.0.0 - Manufacturer SIBA
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Rated current (A) 200
Fuse Connection/Terminal type Cylindrical
Fixing connection centres (mm) 192
Weight (gr) 4500
Price List €787.13/pc
Quantity
lock Datasheet
Isolatore 40,5kV da interno

Isolatore 40,5kV da interno

Reference 3134001.2.0 - Manufacturer SIBA
Rated Voltage Un AC (V) 40500
Applicable standards IEC
Rated current (A) 200A
Fuse Connection/Terminal type Cylindrical
Number of poles 1
Weight (gr) 9060
Price List €770.67/pc
Quantity
lock Datasheet
Fuse 36kV TV 22x360 0,1A

Fuse 36kV TV 22x360 0,1A

Reference 3044511.0,1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,1
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 7
Melting I²t value (A²s) 0,14
Voltage of total clearing I2t test 36000
Total clearing I²t @Un AC (A²s) 0,15
Rated breaking capacity I1 AC (kA) 40000
Price List €233.66/pc
Quantity
lock Datasheet
Fuse 36kV TV 22x360 1A

Fuse 36kV TV 22x360 1A

Reference 3044511.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 6.3
Melting I²t value (A²s) 1,8
Voltage of total clearing I2t test 36000
Total clearing I²t @Un AC (A²s) 13
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 36kV TV 22x360 2A

Fuse 36kV TV 22x360 2A

Reference 3044511.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 24
Melting I²t value (A²s) 2,9
Voltage of total clearing I2t test 36000
Total clearing I²t @Un AC (A²s) 21
Rated breaking capacity I1 AC (kA) 40000
Price List €292.07/pc
Quantity
lock Datasheet
Fuse BR Motors 7,2kV 403mm 230A

Fuse BR Motors 7,2kV 403mm 230A

Reference 3045955.12R.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 230
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 105
Fuse Dimension (mm) 76x403
Melting I²t value (A²s) 170000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6300
Total clearing I²t @Un AC (A²s) 930000
Rated breaking capacity I1 AC (kA) 50000
Product available on request Ask for more information
Fuse BR Motors 7,2kV 403mm 70A

Fuse BR Motors 7,2kV 403mm 70A

Reference 3045955.2R.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 70
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 55
Fuse Dimension (mm) 76x403
Melting I²t value (A²s) 6300
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6300
Total clearing I²t @Un AC (A²s) 37500
Rated breaking capacity I1 AC (kA) 50000
Product available on request Ask for more information
Fuse BR Motors 7,2kV 403mm 100A

Fuse BR Motors 7,2kV 403mm 100A

Reference 3045955.3R.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 100
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 81
Fuse Dimension (mm) 76x403
Melting I²t value (A²s) 9000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6300
Total clearing I²t @Un AC (A²s) 47000
Rated breaking capacity I1 AC (kA) 50000
Product available on request Ask for more information
Fuse BR Motors 7,2kV 403mm 130A

Fuse BR Motors 7,2kV 403mm 130A

Reference 3045955.4R.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 130
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 93
Fuse Dimension (mm) 76x403
Melting I²t value (A²s) 20400
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6300
Total clearing I²t @Un AC (A²s) 122000
Rated breaking capacity I1 AC (kA) 50000
Product available on request Ask for more information
