Fuse NH3 1000VDC gPV 250A

Reference 373435B.0.0 - Manufacturer DF

Class	gPV
Rated current In (A)	250
Dimension	NH3
Applicable standards	IEC
Power loss (W)	51,5
Rated Voltage Un DC (V)	1000
Rated breaking capacity I1 DC (kA)	30000
Melting I²t value (A²s)	41000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	60000

Price List €139.05/pc

Quantity

Fuse NH3 1000VDC gPV UL2579 315A

Reference 373445.0.0 - Manufacturer DF

Class	gPV
Rated current In (A)	315
Dimension	NH3
Applicable standards	IEC, UL
Power loss (W)	66
Rated Voltage Un DC (V)	1000
Rated breaking capacity I1 DC (kA)	30000
Melting I²t value (A²s)	76000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1000
Total clearing I²t @Un AC (A²s)	111500
Weight (gr)	1280

Price List €231.75/pc

Quantity

Fuse NH3 1000VDC gPV 315A

Reference 373445B.0.0 - Manufacturer DF

Class	gPV
Rated current In (A)	315
Dimension	NH3
Applicable standards	IEC
Power loss (W)	66
Rated Voltage Un DC (V)	1000
Rated breaking capacity I1 DC (kA)	30000
Melting I²t value (A²s)	76000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	111500

Price List €139.05/pc

Quantity

Fuse NH3 1000VDC gPV 355A

Reference 373450.0.0 - Manufacturer DF

Class	gPV
Rated current In (A)	355
Dimension	NH3
Applicable standards	IEC
Power loss (W)	46,5
Rated Voltage Un DC (V)	1000
Rated breaking capacity I1 DC (kA)	30000
Melting I²t value (A²s)	74700
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1000
Total clearing I²t @Un AC (A²s)	130700
Weight (gr)	1280

Price List €235.32/pc

Quantity

Fuse base NH00 1P fix. screw - conn. clamp/screw

Reference 354110.0.0 - Manufacturer DF

Rated current In (A)	160
Rated Voltage Un AC (V)	800
Dimension	NH00
Applicable standards	IEC
Rated Voltage Un DC (V)	750
Max power dissipation (W)	12
Fuse Connection/Terminal type	NH knife
Number of poles	3
Weight (gr)	120

Price List €5.74/pc

Quantity

lock Datasheet

Fuse holder polyester ST NH4 1pole (2 bases) 2500A screw fix

Reference 354127.0.0 - Manufacturer DF

Rated current In (A)	2500
Rated Voltage Un AC (V)	690
Dimension	NH4
Applicable standards	IEC
Rated Voltage Un DC (V)	750
Fuse Connection/Terminal type	NH knife
Number of poles	1
Weight (gr)	3000

Price List €370.32/pc

Quantity

lock Datasheet

Base NH4 1P 690VAC/750VDC conn. double screw

Reference 354128.0.0 - Manufacturer DF

Rated current In (A)	500
Dimension	NH3
Applicable standards	IEC, UL
Rated Voltage Un DC (V)	1000
Max power dissipation (W)	60
Fuse Connection/Terminal type	NH knife
Weight (gr)	630

Price List €139.13/pc

Quantity

lock Datasheet

Fuse holder polyester 1P NH2 1000VDC DINrail or screw fixing

Reference 354175.0.0 - Manufacturer DF

Rated current In (A)	400
Dimension	NH2
Applicable standards	IEC, UL
Rated Voltage Un DC (V)	1000
Max power dissipation (W)	45
Fuse Connection/Terminal type	NH knife
Number of poles	1
Weight (gr)	509

Price List €55.92/pc

Quantity

lock Datasheet

Fuse holder polyester 1P NH3 1000VDC DINrail or screw fixing

Reference 354180.0.0 - Manufacturer DF

Rated current In (A)	500
Dimension	NH3
Applicable standards	IEC, UL
Rated Voltage Un DC (V)	1000
Fuse Connection/Terminal type	NH knife
Number of poles	1
Weight (gr)	630

Price List €82.93/pc

Quantity

lock Datasheet

Polyester base NH2 1P screw fixing fixed nut connection

Reference 354251.0.0 - Manufacturer DF

Rated current In (A)	400
Rated Voltage Un AC (V)	800
Dimension	NH2
Applicable standards	IEC
Rated Voltage Un DC (V)	750
Max power dissipation (W)	45
Fuse Connection/Terminal type	NH knife
Number of poles	1
Weight (gr)	500

Price List €38.93/pc

Quantity

lock Datasheet

Busbar pin 4poles isolated 17,6mm/70,4mm 3544

Reference 3544.0.0 - Manufacturer FTG

Type	Pin
Number of connections	12
Cross section (mm2)	10
Fixing connection centres (mm)	17
Number of poles	4

Product available on request Ask for more information

Busbar pin 4poles isolated 17,6mm/70,4mm 3546

Reference 3546.0.0 - Manufacturer FTG

Type	Pin
Number of connections	56
Cross section (mm2)	10
Fixing connection centres (mm)	17
Number of poles	4

Product available on request Ask for more information

Busbar pin 4poles isolated 17,6mm/70,4mm 3548

Reference 3548.0.0 - Manufacturer FTG

Type	Pin
Number of connections	12
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	4

Product available on request Ask for more information

Busbar pin 4poles isolated 17,6mm/70,4mm 3550

Reference 3550.0.0 - Manufacturer FTG

Type	Pin
Number of connections	56
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	4

Product available on request Ask for more information

Fuse base NH0 3P fix. screw - conn. screw

Reference 355160.0.0 - Manufacturer DF

Rated current In (A)	160
Rated Voltage Un AC (V)	690
Dimension	NH0
Applicable standards	IEC
Rated Voltage Un DC (V)	750
Max power dissipation (W)	25
Fuse Connection/Terminal type	NH knife
Weight (gr)	620

Price List €39.98/pc

Quantity

lock Datasheet

Busbar fork 4poles isolated 17,6mm/35,2mm 3560

Reference 3560.0.0 - Manufacturer FTG

Type	Fork
Number of connections	12
Cross section (mm2)	10
Fixing connection centres (mm)	17
Number of poles	4

Product available on request Ask for more information

Fuse base NH4 1P 690V fix. vite - conn. screw

Reference 356127.0.0 - Manufacturer DF

Rated current In (A)	2500
Rated Voltage Un AC (V)	690
Dimension	NH4
Applicable standards	IEC
Rated Voltage Un DC (V)	750
Max power dissipation (W)	90
Fuse Connection/Terminal type	NH knife
Weight (gr)	5650

Product available on request Ask for more information

Fuse base NH4 1P 690V fix. vite - conn. 2 screws

Reference 356128.0.0 - Manufacturer DF

Rated current In (A)	1250
Rated Voltage Un AC (V)	690
Dimension	NH4
Applicable standards	IEC
Rated Voltage Un DC (V)	750
Max power dissipation (W)	90
Fuse Connection/Terminal type	NH knife
Weight (gr)	2450
