ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P with ind

ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P with ind

Reference 421.781.29.0.0 - Manufacturer FAULTRAP
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Weight (g) 64
Format Cylindrical
Homologations IEC
Fuses dimension 10x38
Rated Voltage Un DC (V) 1000
Number of phase 1
Max power dissipation (W) 4,3
Series name ZVJM
Price List €8.73/pc
Quantity
ZOIG - Fuse base metal/ceramic NH2XL 1500V

ZOIG - Fuse base metal/ceramic NH2XL 1500V

Reference 429.543.63.0.0 - Manufacturer FAULTRAP
Rated current In (A) 400
Rated Voltage Un AC (V) 1000
Weight (g) 750
Format NH knife contact
Dimension NH2XL
Homologations IEC
Rated Voltage Un DC (V) 1500
Number of phase 1
Distance (mm) 258
Max power dissipation (W) 45
Series name ZOIG
Price List €27.68/pc
Quantity
lock Datasheet
ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P

ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P

Reference 793.159.36.0.0 - Manufacturer FAULTRAP
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Weight (g) 124
Homologations IEC
Fuses format Cylindrical
Fuses dimension 10x38mm
Rated Voltage Un DC (V) 1000
Number of phase 2
Max power dissipation (W) 4,3
Series name ZVJM
Price List €8.19/pc
Quantity
lock Datasheet
ZPYT - Fuse holder 22x65 1000VAC/1500VDC 3P

ZPYT - Fuse holder 22x65 1000VAC/1500VDC 3P

Reference 942.799.14.0.0 - Manufacturer FAULTRAP
Rated current In (A) 100
Rated Voltage Un AC (V) 1000
Weight (g) 560
Homologations IEC
Fuses format Cylindrical
Fuses dimension 22x65mm
Rated Voltage Un DC (V) 1500
Number of phase 3
Max power dissipation (W) 12
Series name ZPYT
Price List €28.42/pc
Quantity
ZPYT - Fuse holder 22x65 1250VAC/1500VDC IEC/UL 1P

ZPYT - Fuse holder 22x65 1250VAC/1500VDC IEC/UL 1P

Reference 845.025.35.0.0 - Manufacturer FAULTRAP
Rated current In (A) 100
Rated Voltage Un AC (V) 1250
Weight (g) 186
Fuses format Cylindrical
Fuses dimension 22x65mm
Rated Voltage Un DC (V) 1500
Number of phase 1
Max power dissipation (W) 12
Series name ZPYT
Price List €8.70/pc
Quantity
ZVJM - Fuse holder 10x38 690VAC-1000VDC 3P

ZVJM - Fuse holder 10x38 690VAC-1000VDC 3P

Reference 609.223.86.0.0 - Manufacturer FAULTRAP
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Weight (g) 187
Homologations IEC
Power loss (W) 4
Fuses format Cylindrical
Fuses dimension 10x38mm
Rated Voltage Un DC (V) 1000
Number of phase 3
Series name ZVJM
Price List €12.68/pc
Quantity
lock Datasheet
ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P

ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P

Reference 832.456.76.0.0 - Manufacturer FAULTRAP
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Weight (g) 62
Homologations IEC
Fuses format Cylindrical
Fuses dimension 10x38mm
Rated Voltage Un DC (V) 1000
Number of phase 1
Max power dissipation (W) 4
Series name ZVJM
Price List €3.35/pc
Quantity
lock Datasheet
ZFYJ - Fuse base NH2XL/NH3L 400A 1500VDC

ZFYJ - Fuse base NH2XL/NH3L 400A 1500VDC

Reference 255.167.93.0.0 - Manufacturer FAULTRAP
Rated current In (A) 400
Rated Voltage Un AC (V) 1000
Weight (g) 764
Format NH knife contact
Dimension NH2XL
Homologations IEC
Rated Voltage Un DC (V) 1500
Number of phase 1
Distance (mm) 267
Max power dissipation (W) 45
Series name ZFYJ
Price List €113.65/pc
Quantity
lock Datasheet
ZJLR - Fuse base NH1 1500VDC 1P

ZJLR - Fuse base NH1 1500VDC 1P

Reference 447.520.55.0.0 - Manufacturer FAULTRAP
Rated current In (A) 250
Rated Voltage Un AC (V) 1000
Weight (g) 610
Homologations IEC
Fuses format NH knife contact
Fuses dimension NH1
Rated Voltage Un DC (V) 1500
Number of phase 1
Distance (mm) 175
Max power dissipation (W) 32
Series name ZJLR
Price List €28.39/pc
Quantity
lock Datasheet
ZLIY - Fuse base metal/ceramic NH3L 1500V

ZLIY - Fuse base metal/ceramic NH3L 1500V

Reference 837.607.45.0.0 - Manufacturer FAULTRAP
Rated current In (A) 630
Weight (g) 1018
Homologations IEC
Fuses format NH knife contact
Fuses dimension NH3L
Rated Voltage Un DC (V) 1500
Number of phase 1
Distance (mm) 267
Max power dissipation (W) 60
Series name ZLIY
Price List €152.66/pc
Quantity
lock Datasheet
ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P with ind

ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P with ind

Reference 543.991.81.0.0 - Manufacturer FAULTRAP
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Weight (g) 129
Homologations IEC
Fuses format Cylindrical
Fuses dimension 10x38mm
Rated Voltage Un DC (V) 1000
Number of phase 2
Max power dissipation (W) 4,3
Series name ZVJM
Price List €3.51/pc
Quantity
lock Datasheet
AR22 - EV Charger Fuse 1000VDC 50A

AR22 - EV Charger Fuse 1000VDC 50A

Reference 260.036.14.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 50
Weight (g) 60
Format Cylindrical
Pre-arcing I2t value (A2s) 737
Total I2t value (A2s) 6600
Homologations IEC
Power loss (W) 9
Fuses dimension 22x65
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 50000
Series name AR22
Product available on request Ask for more information
AR22 - EV Charger Fuse 1000VDC 70A

AR22 - EV Charger Fuse 1000VDC 70A

Reference 529.658.33.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 70
Weight (g) 60
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 2000
Total I2t value (A2s) 12300
Homologations IEC
Power loss (W) 12,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 50000
Series name AR22
Price List €11.89/pc
Quantity
AR22 - EV Charger Fuse 1000VDC 60A

AR22 - EV Charger Fuse 1000VDC 60A

Reference 595.927.40.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 60
Weight (g) 60
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 1300
Total I2t value (A2s) 9800
Homologations IEC
Power loss (W) 9,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 50000
Series name AR22
Product available on request Ask for more information
VP22 - Fuse 22x65mm 1500VDC gPV IEC 50A

VP22 - Fuse 22x65mm 1500VDC gPV IEC 50A

Reference 635.145.22.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 50
Voltage of total I2t test 1500
Weight (g) 60
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 740
Total I2t value (A2s) 6550
Homologations IEC
Power loss (W) 9
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 10000
Time costant L/R (ms) 3
Series name VP22
Product available on request Ask for more information
VP22 - Fuse 22x65mm 1500VDC gPV/800VAC gR IEC 40A

VP22 - Fuse 22x65mm 1500VDC gPV/800VAC gR IEC 40A

Reference 360.932.23.0.0 - Manufacturer FAULTRAP
Rated current In (A) 40
Rated Voltage Un AC (V) 800
Voltage of total I2t test 1500
Weight (g) 60
Format Cylindrical
Pre-arcing I2t value (A2s) 420
Total I2t value (A2s) 3650
Homologations IEC
Power loss (W) 7
Fuses dimension 22x65
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 10000
Time costant L/R (ms) 3
Series name VP22
Price List €15.74/pc
Quantity
VP22 - Fuse 22x65mm 1500VDC gPV IEC 32A

VP22 - Fuse 22x65mm 1500VDC gPV IEC 32A

Reference 845.638.80.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 32
Voltage of total I2t test 1500
Weight (g) 60
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 190
Total I2t value (A2s) 1650
Homologations IEC
Power loss (W) 6,3
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 10000
Time costant L/R (ms) 3
Series name VP22
Product available on request Ask for more information
Fuse 2x SQB3 M12 aR 690V lateral switch adapter 2800A

Fuse 2x SQB3 M12 aR 690V lateral switch adapter 2800A

Reference 2068832.2800.0 - Manufacturer SIBA
Class aR
Rated current In (A) 2800
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 1650
Format Screw fixing
Dimension 2x SQB3 screw M12
Pre-arcing I2t value (A2s) 1520000
Total I2t value (A2s) 8800000
Homologations IEC
Power loss (W) 340
Price List €222.30/pc
Quantity
lock Datasheet
Fuse NH1 800V gG 160A

Fuse NH1 800V gG 160A

Reference 2031113.160.0 - Manufacturer SIBA
Class gG
Rated current In (A) 160
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Dimension NH1
Pre-arcing I2t value (A2s) 60000
Total I2t value (A2s) 310000
Homologations IEC
Power loss (W) 13
Price List €18.77/pc
Quantity
Fuse NH1 800V gG 160A

Fuse NH1 800V gG 160A

Reference 2031113.160.0 - Manufacturer SIBA
Class gG
Rated current In (A) 160
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Format NH knife contact
Dimension NH1
Pre-arcing I2t value (A2s) 60000
Total I2t value (A2s) 240000
Homologations IEC
Power loss (W) 13
Price List €36.89/pc
Quantity
Fuse NH1 800V gG 125A

Fuse NH1 800V gG 125A

Reference 2031113.125.0 - Manufacturer SIBA
Class gG
Rated current In (A) 125
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Format NH knife contact
Dimension NH1
Pre-arcing I2t value (A2s) 30000
Total I2t value (A2s) 160000
Homologations IEC
Power loss (W) 10
Price List €35.30/pc
Quantity
Fuse NH1 800V gG 80A

Fuse NH1 800V gG 80A

Reference 2031113.80.0 - Manufacturer SIBA
Class gG
Rated current In (A) 80
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Format NH knife contact
Dimension NH1
Pre-arcing I2t value (A2s) 10000
Total I2t value (A2s) 55000
Homologations IEC
Power loss (W) 7,5
Price List €88.81/pc
Quantity
Fuse NH3 800V gG 250A

Fuse NH3 800V gG 250A

Reference 2031313.250.0 - Manufacturer SIBA
Class gG
Rated current In (A) 250
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Weight (g) 1080
Format NH knife contact
Dimension NH3
Pre-arcing I2t value (A2s) 170000
Total I2t value (A2s) 905000
Homologations IEC
Power loss (W) 20
Price List €53.88/pc
Quantity
lock Datasheet
Fuse NH1 800V gG 100A

Fuse NH1 800V gG 100A

Reference 2031113.100.0 - Manufacturer SIBA
Class gG
Rated current In (A) 100
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Format NH knife contact
Dimension NH1
Pre-arcing I2t value (A2s) 20000
Total I2t value (A2s) 110000
Homologations IEC
Power loss (W) 9
Price List €88.97/pc
Quantity
BSDC - Fuse 2x38x73mm 1000VDC BS aBat 500A

BSDC - Fuse 2x38x73mm 1000VDC BS aBat 500A

Reference 233.082.62.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 500
Voltage of total I2t test 1018
Weight (g) 455
Format Screw fixing
Pre-arcing I2t value (A2s) 84000
Total I2t value (A2s) 319000
Homologations IEC
Power loss (W) 78
Fuses dimension 38x73
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 50000
Time costant L/R (ms) 2
Series name BSDC
Price List €128.01/pc
Quantity
lock Datasheet
BSDC - Fuse 38x73mm 1000VDC BS aBat 250A

BSDC - Fuse 38x73mm 1000VDC BS aBat 250A

Reference 631.812.67.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 250
Voltage of total I2t test 1018
Weight (g) 225
Format Screw fixing
Dimension 38x73mm
Pre-arcing I2t value (A2s) 21000
Total I2t value (A2s) 79800
Homologations IEC
Power loss (W) 39
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 50000
Time costant L/R (ms) 2
Series name BSDC
Product available on request Ask for more information
Fuse holder 10x38 690VAC/750VDC 3poles + N

Fuse holder 10x38 690VAC/750VDC 3poles + N

Reference 5106305.3N.0 - Manufacturer SIBA
Rated current In (A) 30
Rated Voltage Un AC (V) 690
Weight (g) 64
Fuses format Cylindrical
Fuses dimension 10x38mm
Rated Voltage Un DC (V) 750
Number of phase 4
Max power dissipation (W) 4
Price List €119.30/pc
Quantity
lock Datasheet
Filter by
Manufacturer
Class
Rated Voltage Un AC (V)
Series name
more... less
Rated Voltage Un DC (V)
Rated insultaion voltage AC (V)
Rated insulated voltage DC (V)
Fuses format
Fuses dimension
Inside diameter (mm)
Distance (mm)
Homologations
Product added to compare.
Product added to wishlist
