T500 - Fuse 500VDC aBat d:38mm axial 80mm 200A

T500 - Fuse 500VDC aBat d:38mm axial 80mm 200A

Reference 224.219.21.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 200
Voltage of total I2t test 500
Format Screw fixing
Pre-arcing I2t value (A2s) 10400
Total I2t value (A2s) 15500
Power loss (W) 19
Fuses dimension 38x80
Rated Voltage Un DC (V) 500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name T500
Product available on request Ask for more information
B100 - Fuse 1000VDC aBat 700A - 152,7mm - Silver Plated

B100 - Fuse 1000VDC aBat 700A - 152,7mm - Silver Plated

Reference 224.928.92.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 700
Voltage of total I2t test 1000
Format Screw fixing
Pre-arcing I2t value (A2s) 143600
Total I2t value (A2s) 431000
Power loss (W) 128
Fuses dimension 63,5x130,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B100
Min breaking current (A) 7000
Product available on request Ask for more information
B100 - Fuse 1000VDC aBat 1000A - 152,7mm - Silver Plated

B100 - Fuse 1000VDC aBat 1000A - 152,7mm - Silver Plated

Reference 225.952.24.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1000
Voltage of total I2t test 1000
Format Screw fixing
Pre-arcing I2t value (A2s) 373500
Total I2t value (A2s) 1095000
Power loss (W) 175
Fuses dimension 63,5x130,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B100
Min breaking current (A) 10000
Product available on request Ask for more information
B025 - Fuse 1000VDC aBat 200A - 100,3mm - Silver Plated

B025 - Fuse 1000VDC aBat 200A - 100,3mm - Silver Plated

Reference 290.646.80.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 200
Voltage of total I2t test 1000
Format Screw fixing
Pre-arcing I2t value (A2s) 10400
Total I2t value (A2s) 23000
Power loss (W) 30
Fuses dimension 38,10x72,20
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B025
Min breaking current (A) 1600
Product available on request Ask for more information
T500 - Fuse 500VDC aBat d:38mm axial 80mm 125A

T500 - Fuse 500VDC aBat d:38mm axial 80mm 125A

Reference 297.366.16.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 125
Voltage of total I2t test 500
Format Screw fixing
Pre-arcing I2t value (A2s) 3500
Total I2t value (A2s) 5300
Power loss (W) 12
Fuses dimension 38x80
Rated Voltage Un DC (V) 500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name T500
Product available on request Ask for more information
Fuse 12kV 67x292 back-up with striker 63A 120N

Fuse 12kV 67x292 back-up with striker 63A 120N

Reference 3001214.63.0 - Manufacturer SIBA
Rated current In (A) 63
Rated Voltage Un AC (V) 12000
Rated break.capacity I1 AC (A) 63000
Voltage of total I2t test 10440
Weight (g) 2530
Format Cylindrical
Dimension 67x292mm
Pre-arcing I2t value (A2s) 8700
Total I2t value (A2s) 67000
Homologations IEC
Power loss (W) 64
Resistance (ohm) 0,0117
Min breaking current (A) 210
Price List €96.45/pc
Quantity
lock Datasheet
Fuse 7,2kV 87x192 back-up striker no temp.lim200ARC140

Fuse 7,2kV 87x192 back-up striker no temp.lim200ARC140

Reference 3001814.200LM.0 - Manufacturer SIBA
Rated current In (A) 200
Rated Voltage Un AC (V) 7200
Rated break.capacity I1 AC (A) 80000
Voltage of total I2t test 6264
Format Cylindrical
Dimension 85x192mm
Pre-arcing I2t value (A2s) 225000
Total I2t value (A2s) 965000
Homologations IEC
Power loss (W) 53
Resistance (ohm) 0,0019
Min breaking current (A) 800
Price List €323.31/pc
Quantity
lock Datasheet
Fuse 7,2kV 87x192 back-up striker no temp.lim250ARC160

Fuse 7,2kV 87x192 back-up striker no temp.lim250ARC160

Reference 3001814.250LM.0 - Manufacturer SIBA
Rated current In (A) 250
Rated Voltage Un AC (V) 7200
Rated break.capacity I1 AC (A) 80000
Voltage of total I2t test 6264
Format Cylindrical
Dimension 85x192mm
Pre-arcing I2t value (A2s) 265000
Total I2t value (A2s) 1100000
Homologations IEC
Power loss (W) 66
Resistance (ohm) 0,0018
Operating voltage (V) False
Min breaking current (A) 1000
Price List €343.66/pc
Quantity
lock Datasheet
Fuse 12kV 87x292 back-up striker no temp.lim200ARC125

Fuse 12kV 87x292 back-up striker no temp.lim200ARC125

Reference 3002014.200LM.0 - Manufacturer SIBA
Rated current In (A) 200
Rated Voltage Un AC (V) 6000
Rated break.capacity I1 AC (A) 80000
Voltage of total I2t test 5220
Format Cylindrical
Dimension 85x292mm
Pre-arcing I2t value (A2s) 227000
Total I2t value (A2s) 1300000
Homologations IEC
Power loss (W) 71
Resistance (ohm) 0,0032
Min breaking current (A) 870
Price List €517.81/pc
Quantity
lock Datasheet
Fuse 12kV 87x292 back-up striker no temp.lim250ARC140

Fuse 12kV 87x292 back-up striker no temp.lim250ARC140

Reference 3002014.250LM.0 - Manufacturer SIBA
Rated current In (A) 250
Rated Voltage Un AC (V) 6000
Rated break.capacity I1 AC (A) 80000
Voltage of total I2t test 5220
Format Cylindrical
Dimension 85x292mm
Pre-arcing I2t value (A2s) 265000
Total I2t value (A2s) 1800000
Homologations IEC
Power loss (W) 81
Resistance (ohm) 0,003
Min breaking current (A) 1000
Price List €419.76/pc
Quantity
lock Datasheet
Fuse 7,2kV 87x292 back-up striker no temp.lim315ARC200

Fuse 7,2kV 87x292 back-up striker no temp.lim315ARC200

Reference 3010014.315LM.0 - Manufacturer SIBA
Rated current In (A) 315
Rated Voltage Un AC (V) 7200
Rated break.capacity I1 AC (A) 80000
Voltage of total I2t test 6264
Format Cylindrical
Dimension 85x292mm
Pre-arcing I2t value (A2s) 551000
Total I2t value (A2s) 2200000
Homologations IEC
Power loss (W) 76
Resistance (ohm) 0,0013
Min breaking current (A) 1250
Price List €662.22/pc
Quantity
lock Datasheet
Fuse 12kV 87x442 back-up striker no temp.lim250ARC200

Fuse 12kV 87x442 back-up striker no temp.lim250ARC200

Reference 3010314.250LM.0 - Manufacturer SIBA
Rated current In (A) 250
Rated Voltage Un AC (V) 6000
Rated break.capacity I1 AC (A) 80000
Voltage of total I2t test 5220
Format Cylindrical
Dimension 85x442mm
Pre-arcing I2t value (A2s) 265700
Total I2t value (A2s) 1800000
Homologations IEC
Power loss (W) 148
Resistance (ohm) 0,0024
Min breaking current (A) 1000
Price List €578.45/pc
Quantity
lock Datasheet
