Fuses

Showing 10945-10980 of 11319 item(s)

Fuse NH2L 1000V aM with switch adapter 80A

Reference 2028808.80.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	80
Rated Voltage Un AC (V)	1000
Dimension	NH2L
Power loss (W)	8
Melting I²t value (A²s)	18700
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1100
Total clearing I²t @Un AC (A²s)	46700
Rated breaking capacity I1 AC (kA)	80000
Weight (gr)	900

Product available on request Ask for more information

Fuse SQB-DC203 2000VDC gPV M12 250A

Reference 2032329.250.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	250
Applicable standards	IEC
Power loss (W)	70
Rated Voltage Un DC (V)	2000
Time costant L/R (ms)	6
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	42000
Fuse Connection/Terminal type	Screw fixing

Product available on request Ask for more information

Fuse SQB-DC203 2000VDC gPV M12 315A

Reference 2032329.315.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	315
Applicable standards	IEC
Power loss (W)	80
Rated Voltage Un DC (V)	2000
Time costant L/R (ms)	6
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	74000
Fuse Connection/Terminal type	Screw fixing

Product available on request Ask for more information

Fuse 400V NH1 gG 16A

Reference 2026413.16.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	16
Rated Voltage Un AC (V)	400
Dimension	NH1
Applicable standards	IEC
Power loss (W)	2
Melting I²t value (A²s)	410
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	810
Rated breaking capacity I1 AC (kA)	120000

Price List €5.20/pc

Quantity

lock Datasheet

Fuse 400V NH1 gG 20A

Reference 2026413.20.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	20
Rated Voltage Un AC (V)	400
Dimension	NH1
Applicable standards	IEC
Power loss (W)	2,3
Melting I²t value (A²s)	690
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	1550
Rated breaking capacity I1 AC (kA)	120000

Price List €5.20/pc

Quantity

lock Datasheet

Fuse 400V NH2 gG 20A

Reference 2026513.20.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	20
Rated Voltage Un AC (V)	400
Dimension	NH2
Applicable standards	IEC
Melting I²t value (A²s)	690
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	1550
Rated breaking capacity I1 AC (kA)	120000

Product available on request Ask for more information

Fuse 400V NH2 gG 25A

Reference 2026513.25.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	25
Rated Voltage Un AC (V)	400
Dimension	NH2
Applicable standards	IEC
Melting I²t value (A²s)	1400
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	3000
Rated breaking capacity I1 AC (kA)	120000

Product available on request Ask for more information

Fuse 400V NH2 gG 32A

Reference 2026513.32.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	32
Rated Voltage Un AC (V)	400
Dimension	NH2
Applicable standards	IEC
Melting I²t value (A²s)	2950
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	5800
Rated breaking capacity I1 AC (kA)	120000

Product available on request Ask for more information

Fuse 400V NH3 gG 125A

Reference 2026613.125.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	125
Rated Voltage Un AC (V)	400
Dimension	NH3
Applicable standards	IEC
Melting I²t value (A²s)	43000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	15000
Rated breaking capacity I1 AC (kA)	120000

Price List €126.26/pc

Quantity

lock Datasheet

Fuse 400V NH3 gG 224A

Reference 2026613.224.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	224
Rated Voltage Un AC (V)	400
Dimension	NH3
Applicable standards	IEC
Melting I²t value (A²s)	185000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	585000
Rated breaking capacity I1 AC (kA)	120000

Product available on request Ask for more information

Fuse 400V NH3 gG 80A

Reference 2026613.80.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	80
Rated Voltage Un AC (V)	400
Dimension	NH3
Applicable standards	IEC
Melting I²t value (A²s)	15500
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	47500
Total clearing I²t @Un AC (A²s)	28500
Rated breaking capacity I1 AC (kA)	120000

Price List €126.26/pc

Quantity

lock Datasheet

Fuse NH2 gG 500V 35A weatherresistant

Reference 2023913.35.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	35
Rated Voltage Un AC (V)	500
Dimension	NH2
Applicable standards	IEC
Power loss (W)	3,9
Melting I²t value (A²s)	3100
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	7610
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	320

Product available on request Ask for more information

Fuse NH2 gG 500V 355A weatherresistant

Reference 2023913.355.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	355
Rated Voltage Un AC (V)	500
Dimension	NH2
Applicable standards	IEC
Power loss (W)	30
Melting I²t value (A²s)	616000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	1483000
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	700

Product available on request Ask for more information

Fuse NH2 gG 500V 40A weatherresistant

Reference 2023913.40.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	40
Rated Voltage Un AC (V)	500
Dimension	NH2
Applicable standards	IEC
Power loss (W)	4,3
Melting I²t value (A²s)	4700
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	11300
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	320

Product available on request Ask for more information

Fuse NH2 gG 500V 50A weatherresistant

Reference 2023913.50.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	50
Rated Voltage Un AC (V)	500
Dimension	NH2
Applicable standards	IEC
Power loss (W)	5,1
Melting I²t value (A²s)	5900
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	440
Total clearing I²t @Un AC (A²s)	13600
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	320

Product available on request Ask for more information

Fuse 1500V DC gR NH3L 100A

Reference 2024336.100.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	100
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	20
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	3000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	30000

Product available on request Ask for more information

Fuse 1500V DC gR NH3L 250A

Reference 2024336.250.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	250
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	45
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	31500
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	220000

Product available on request Ask for more information

Fuse 1500V DC gR NH3L 315A

Reference 2024336.315.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	315
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	55
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	56000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	392000

Product available on request Ask for more information

Fuse 1500V DC gR NH3L 450A

Reference 2024336.450.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	450
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	74
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	153000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	1075000

Product available on request Ask for more information

Fuse 1500V DC gR NH3L 500A

Reference 2024336.500.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	500
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	82
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	189000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	1325000

Product available on request Ask for more information

Fuse 1500V DC gR NH3L with micro adp 100A

Reference 2024337.100.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	100
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	20
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	3000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	30000

Price List €166.30/pc

Quantity

lock Datasheet

Fuse 1500V DC gR NH3L with micro adp 160A

Reference 2024337.160.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	160
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	33
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	9500
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	80000

Price List €182.85/pc

Quantity

lock Datasheet

Fuse 1500V DC gR NH3L with micro adp 200A

Reference 2024337.200.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	200
Dimension	NH3L
Applicable standards	IEC, UL
Power loss (W)	38
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	18000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	126000

Price List €149.48/pc

Quantity

lock Datasheet

Fuse SQB3 167mm gPV DC 1500V no ind 200A

Reference 2024528.200.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	200
Applicable standards	IEC, UL
Power loss (W)	37
Rated Voltage Un DC (V)	1500
Melting I²t value (A²s)	19200
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	108000

Product available on request Ask for more information

Fuse SQB3 167mm gPV DC 1500V no ind 250A

Reference 2024528.250.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	250
Applicable standards	IEC, UL
Power loss (W)	43
Rated Voltage Un DC (V)	1500
Melting I²t value (A²s)	32000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	192000

Product available on request Ask for more information

Fuse SQB3 167mm gPV DC 1500V no ind 350A

Reference 2024528.350.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	350
Applicable standards	IEC, UL
Power loss (W)	60
Rated Voltage Un DC (V)	1500
Melting I²t value (A²s)	77000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	480000

Product available on request Ask for more information

Fuse SQB3 167mm gPV DC 1500V no ind 400A

Reference 2024528.400.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	400
Applicable standards	IEC, UL
Power loss (W)	65
Rated Voltage Un DC (V)	1500
Melting I²t value (A²s)	106000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	640000

Product available on request Ask for more information

Fuse SQB3 167mm gPV DC 1500V no ind 400A

Reference 2024528.450.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	450
Applicable standards	IEC, UL
Power loss (W)	70
Rated Voltage Un DC (V)	1500
Melting I²t value (A²s)	153000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	920000

Product available on request Ask for more information

Fuse SQB3 167mm gPV DC 1500V no ind 400A

Reference 2024528.500.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	500
Applicable standards	IEC, UL
Power loss (W)	80
Rated Voltage Un DC (V)	1500
Melting I²t value (A²s)	189000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	1010000

Product available on request Ask for more information

Fuse 1500V DC gBat/gR SQB3 knife DIN 167mm 100A

Reference 2024536.100.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	100
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	20
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	3000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	30000

Product available on request Ask for more information

Fuse 1500V DC gBat/gR SQB3 knife DIN 167mm 125A

Reference 2024536.125.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	125
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	24
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	5800
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	47000

Product available on request Ask for more information

Fuse 1500V DC gBat/gR SQB3 knife DIN 167mm 160A

Reference 2024536.160.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	160
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	33
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	9500
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	80000

Product available on request Ask for more information

Fuse 1500V DC gBat/gR SQB3 knife DIN 167mm 200A

Reference 2024536.200.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	200
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	38
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	18000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	126000

Product available on request Ask for more information

Fuse 1500V DC gBat/gR SQB3 knife DIN 167mm 250A

Reference 2024536.250.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	250
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	45
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	31500
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	220000

Product available on request Ask for more information

Fuse 1500V DC gBat/gR SQB3 knife DIN 167mm 400A

Reference 2024536.400.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	400
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	66
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	260000
Melting I²t value (A²s)	106000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	745000

Product available on request Ask for more information

Fuse 1500VDC SQB3 gPV screw fixing switch adapter 200A

Reference 2024727.200.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	200
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	37
Rated Voltage Un DC (V)	1500
Rated breaking capacity I1 DC (kA)	30000
Melting I²t value (A²s)	19200
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	108000

Product available on request Ask for more information

11319 products

01
• • •
304
•
305
•
306
• • •
315

Fuses

INFORMATIONS

ACCOUNT

CONTACT US

NEWSLETTER
