Fuses

Fuse 1100V DC 14x65 gPV IEC 60269-6 8A

Fuse 1100V DC 14x65 gPV IEC 60269-6 8A

Reference 5023526.8.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 8
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 5
Total I2t value (A2s) 22
Homologations IEC
Power loss (W) 2,6
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Product available on request Ask for more information
Fuse 14x65 gPV 1100VDC plap contacts 10A

Fuse 14x65 gPV 1100VDC plap contacts 10A

Reference 5023926.10.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 5
Total I2t value (A2s) 24
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Product available on request Ask for more information
Fuse 14x65 gPV 1100VDC plap contacts 12A

Fuse 14x65 gPV 1100VDC plap contacts 12A

Reference 5023926.12.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 13
Total I2t value (A2s) 62
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Product available on request Ask for more information
Fuse 14x65 gPV 1100VDC plap contacts 16A

Fuse 14x65 gPV 1100VDC plap contacts 16A

Reference 5023926.16.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 16
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 30
Total I2t value (A2s) 143
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Product available on request Ask for more information
Fuse 14x65 gPV 1100VDC plap contacts 20A

Fuse 14x65 gPV 1100VDC plap contacts 20A

Reference 5023926.20.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 20
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 53
Total I2t value (A2s) 143
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Product available on request Ask for more information
Fuse 14x65 gPV 1000VDC plap contacts 30A

Fuse 14x65 gPV 1000VDC plap contacts 30A

Reference 5023926.30.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 30
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 118
Total I2t value (A2s) 950
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Price List €78.06/pc
Quantity
lock Datasheet
Fuse 14x65 gPV 1100VDC plap contacts 8A

Fuse 14x65 gPV 1100VDC plap contacts 8A

Reference 5023926.8.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 8
Voltage of total I2t test 1100
Format Cylindrical
Dimension 14x65mm
Pre-arcing I2t value (A2s) 5
Total I2t value (A2s) 22
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1100
Rated break.capacity I1 DC (A) 30000
Product available on request Ask for more information
Fuse 27x60mm AC 480V 80mm

Fuse 27x60mm AC 480V 80mm

Reference 5053252.25.0 - Manufacturer SIBA
Class aR
Rated current In (A) 160
Rated Voltage Un AC (V) 480
Rated break.capacity I1 AC (A) 100000
Pre-arcing I2t value (A2s) 200000
Total I2t value (A2s) 350000
Homologations IEC
Product available on request Ask for more information
NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 25A

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 25A

Reference 509.191.68.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 25
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 700
Format Screw fixing
Dimension 000-80mm
Pre-arcing I2t value (A2s) 55
Total I2t value (A2s) 200
Power loss (W) 4.6
Rated Voltage Un DC (V) 700
Rated break.capacity I1 DC (A) 30000
Time costant L/R (ms) 2
Series name NR2B
Product available on request Ask for more information
P103 - Fuse 550V DC EV with pins 50 AMP

P103 - Fuse 550V DC EV with pins 50 AMP

Reference 515.316.40.0.0 - Manufacturer FAULTRAP
Rated current In (A) 50
Voltage of total I2t test 550
Dimension 10x38mm
Pre-arcing I2t value (A2s) 385
Total I2t value (A2s) 1200
Homologations IEC
Power loss (W) 8,8
Rated Voltage Un DC (V) 550
Rated break.capacity I1 DC (A) 20000
Time costant L/R (ms) 2
Series name P103
Product available on request Ask for more information
NR2B - Fuse 00/80 aR 690VAC with ind. w/o lug 400A

NR2B - Fuse 00/80 aR 690VAC with ind. w/o lug 400A

Reference 531.773.36.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 690
Format Screw fixing
Dimension 000-80mm
Pre-arcing I2t value (A2s) 27210
Total I2t value (A2s) 156000
Power loss (W) 89
Time costant L/R (ms) 2
Series name NR2B
Price List €25.57/pc
Quantity
P103 - Fuse 550V DC EV with pins 12 AMP

P103 - Fuse 550V DC EV with pins 12 AMP

Reference 534.021.43.0.0 - Manufacturer FAULTRAP
Rated current In (A) 12
Voltage of total I2t test 550
Dimension 10x38mm
Pre-arcing I2t value (A2s) 9
Total I2t value (A2s) 45
Homologations IEC
Power loss (W) 2,9
Rated Voltage Un DC (V) 550
Rated break.capacity I1 DC (A) 20000
Time costant L/R (ms) 2
Series name P103
Product available on request Ask for more information
