Fuses

Fuse VT 7,2kV 39,6x220 0,5A

Fuse VT 7,2kV 39,6x220 0,5A

Reference 3037111.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 1,9
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 0,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 0,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €84.82/pc
Quantity
lock Datasheet
Fuse VT 7,2kV 39,6x220 1A

Fuse VT 7,2kV 39,6x220 1A

Reference 3037111.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 3,1
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 0,6
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 1,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 679
Price List €106.21/pc
Quantity
lock Datasheet
Fuse VT 7,2kV 39,6x220 2A

Fuse VT 7,2kV 39,6x220 2A

Reference 3037111.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 5,5
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 3,2
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 9,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €106.26/pc
Quantity
lock Datasheet
Fuse VT 7,2kV 39,6x220 3A

Fuse VT 7,2kV 39,6x220 3A

Reference 3037111.3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 6,1
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 16,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 47,8
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2000
Price List €106.34/pc
Quantity
lock Datasheet
Fuse VT 7,2kV 39,6x220 4A

Fuse VT 7,2kV 39,6x220 4A

Reference 3037111.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 7,4
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 28,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 85,3
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2000
Price List €64.07/pc
Quantity
lock Datasheet
Fuse VT 7,2kV 39,6x220 5A

Fuse VT 7,2kV 39,6x220 5A

Reference 3037111.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 9
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 40,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 120,7
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2000
Price List €106.39/pc
Quantity
lock Datasheet
Fuse VT 12kV 39,6x220 0,5A

Fuse VT 12kV 39,6x220 0,5A

Reference 3037211.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 3,3
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 0,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 0,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €269.12/pc
Quantity
lock Datasheet
Fuse VT 12kV 39,6x220 1A

Fuse VT 12kV 39,6x220 1A

Reference 3037211.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 5.3
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 0,6
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 1,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €69.39/pc
Quantity
lock Datasheet
Fuse VT 12kV 39,6x220 2A

Fuse VT 12kV 39,6x220 2A

Reference 3037211.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 9,4
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 3,2
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 9,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €114.94/pc
Quantity
lock Datasheet
Fuse VT 12kV 39,6x220 3A

Fuse VT 12kV 39,6x220 3A

Reference 3037211.3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 11
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 16,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 47,8
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €115.07/pc
Quantity
lock Datasheet
Fuse VT 12kV 39,6x220 4A

Fuse VT 12kV 39,6x220 4A

Reference 3037211.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 12
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 28,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 85,3
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €338.74/pc
Quantity
lock Datasheet
Fuse VT 12kV 39,6x220 5A

Fuse VT 12kV 39,6x220 5A

Reference 3037211.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 16
Fuse Dimension (mm) 40x220
Melting I²t value (A²s) 40,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 120,7
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 680
Price List €115.23/pc
Quantity
lock Datasheet
Fuse VT 17,5kV 39,6x340 0,5A

Fuse VT 17,5kV 39,6x340 0,5A

Reference 3037311.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 4,4
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 0,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 17500
Total clearing I²t @Un AC (A²s) 0,9
Rated breaking capacity I1 AC (kA) 36000
Weight (gr) 840
Price List €64.74/pc
Quantity
lock Datasheet
Fuse VT 17,5kV 39,6x340 1A

Fuse VT 17,5kV 39,6x340 1A

Reference 3037311.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 7,4
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 0,6
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 17500
Total clearing I²t @Un AC (A²s) 1,9
Rated breaking capacity I1 AC (kA) 36000
Weight (gr) 840
Price List €117.64/pc
Quantity
lock Datasheet
Fuse VT 17,5kV 39,6x340 2A

Fuse VT 17,5kV 39,6x340 2A

Reference 3037311.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 13
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 3,2
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 17500
Total clearing I²t @Un AC (A²s) 9,9
Rated breaking capacity I1 AC (kA) 36000
Weight (gr) 1044
Price List €116.75/pc
Quantity
lock Datasheet
Fuse VT 17,5kV 39,6x340 3A

Fuse VT 17,5kV 39,6x340 3A

Reference 3037311.3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 15
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 16,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 17500
Total clearing I²t @Un AC (A²s) 47,8
Rated breaking capacity I1 AC (kA) 36000
Weight (gr) 1044
Price List €97.33/pc
Quantity
lock Datasheet
Fuse VT 17,5kV 39,6x340 4A

Fuse VT 17,5kV 39,6x340 4A

Reference 3037311.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 20
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 28,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 17500
Total clearing I²t @Un AC (A²s) 85,3
Rated breaking capacity I1 AC (kA) 36000
Weight (gr) 1044
Price List €118.20/pc
Quantity
lock Datasheet
Fuse VT 17,5kV 39,6x340 5A

Fuse VT 17,5kV 39,6x340 5A

Reference 3037311.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 24
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 40,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 17500
Total clearing I²t @Un AC (A²s) 120,7
Rated breaking capacity I1 AC (kA) 36000
Weight (gr) 1044
Price List €462.05/pc
Quantity
lock Datasheet
Fuse VT 24kV 39,6x340 0,5A

Fuse VT 24kV 39,6x340 0,5A

Reference 3037411.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 6
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 0,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 0,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 840
Price List €404.79/pc
Quantity
lock Datasheet
Fuse VT 24kV 39,6x340 1A

Fuse VT 24kV 39,6x340 1A

Reference 3037411.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 9
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 0,6
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 1,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 995
Price List €130.03/pc
Quantity
lock Datasheet
Fuse VT 24kV 39,6x340 2A

Fuse VT 24kV 39,6x340 2A

Reference 3037411.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 15
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 3,2
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 9,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 1040
Price List €128.85/pc
Quantity
lock Datasheet
Fuse VT 24kV 39,6x340 3A

Fuse VT 24kV 39,6x340 3A

Reference 3037411.3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 17
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 16,1
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 47,8
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 780
Price List €129.88/pc
Quantity
lock Datasheet
Fuse VT 24kV 39,6x340 4A

Fuse VT 24kV 39,6x340 4A

Reference 3037411.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 26
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 28,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 85,3
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 780
Price List €129.72/pc
Quantity
lock Datasheet
Fuse VT 24kV 39,6x340 5A

Fuse VT 24kV 39,6x340 5A

Reference 3037411.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 31
Fuse Dimension (mm) 40x340
Melting I²t value (A²s) 40,9
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 120,7
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 780
Price List €129.85/pc
Quantity
lock Datasheet
Filter by
Manufacturer
Series name
Fuse size
Class
Fuse Connection/Terminal type
Rated current In (A)
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
